SLLCP23-560

Active

BANNER ENGINEERING

LIGHT CURTAIN FINGER/HAND 23MM

Search across all available documentation for this part.

Active

BANNER ENGINEERING

LIGHT CURTAIN FINGER/HAND 23MM

Technical Specifications

Parameters and characteristics for this part

Part	Protective Height [z]	Voltage - Supply	Ingress Protection	Operating Temperature [Max]	Operating Temperature [Min]	Detection Capability	Protection	Features	Operating Range [Min]	Operating Range [Max]	Protective Height	Protective Height [custom]
BANNER ENGINEERING SLLCP23-1400P88	1400 mm	24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Hand	Blanking	0.1 m	12 m
BANNER ENGINEERING SLLCP23-560		24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Finger/Hand	Blanking	0.1 m	12 m	560 mm
BANNER ENGINEERING SLLCP23-840P88	840 mm	24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Hand	Blanking	0.1 m	12 m
BANNER ENGINEERING SLLCP23-1120		24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Finger/Hand	Blanking	0.1 m	12 m		1120 mm
BANNER ENGINEERING SLLCP23-1330P88	1330 mm	24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Hand	Blanking	0.1 m	12 m
BANNER ENGINEERING SLLCP23-1120P88		24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Hand	Blanking	0.1 m	12 m		1120 mm
BANNER ENGINEERING SLLCP23-1750P88		24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Hand	Blanking	0.1 m	12 m	1750 mm
BANNER ENGINEERING SLLCP23-1050-B16	1.05 m	24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Finger/Hand	Blanking	0.1 m	12 m
BANNER ENGINEERING SLLCP23-350P88	350 mm	24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Hand	Blanking	0.1 m	12 m
BANNER ENGINEERING SLLCP23-840-B16	840 mm	24 VDC	IP65 IP67	55 °C	-20 C	23 mm	Finger/Hand	Blanking	0.1 m	12 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 1786.01
Newark	Each	1	$ 1817.00

General part information

Light Curtain 23mm Finger/Hand Blanking
