109E4748M401

Active

Sanyo Denki America Inc.

FAN AXIAL 172X25.4MM 48VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsRotor Balancing Numbering System DC Fan

109E4748M401

Active

Sanyo Denki America Inc.

FAN AXIAL 172X25.4MM 48VDC WIRE

Deep-Dive with AI

DocumentsRotor Balancing Numbering System DC Fan

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	16	$ 84.69

Description

General part information

109E4748 Series

Fan Tubeaxial 48VDC Rectangular/Rounded - 172mm L x 147mm H Ball 183.0 CFM (5.12m³/min) 3 Wire Leads

Documents

Technical documentation and resources

Rotor Balancing

Numbering System DC Fan

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	109E4748M401	109E4748 Series

Air Flow	183 CFM	162 - 240 CFM
Air Flow	5.12 mł/min	4.54 - 6.72 mł/min
Approval Agency	CSA, TUV, UL	CSA, TUV, UL
Bearing Type	Ball	Ball
Current Rating (Amps)	320 mA	0.25 - 320 A
Fan Type	Tubeaxial	Tubeaxial
Features	Speed Sensor (Tach), Locked Rotor Protection	Locked Rotor Sensor, Speed Sensor (Tach), Locked Rotor Protection
Lifetime @ Temp.	40000 Hrs	40000 Hrs
Material - Blade	Plastic	Plastic
Material - Frame	Aluminum	Aluminum
Noise	51 dB(A)	48 - 58 dB
Operating Temperature [Max]	60 °C	60 °C
Operating Temperature [Max]	60 °C	60 °C
Operating Temperature [Min]	-20 °C	-20 °C
Operating Temperature [Min]	-20 C	-20 C
Power (Watts)	15.4 W	12 - 29.8 W
RPM	2800 RPM	2500 - 3650 RPM
Size / Dimension	Rectangular/Rounded	Rectangular/Rounded
Size / Dimension [x]	172 mm	172 mm
Size / Dimension [y]	147 mm	147 mm
Static Pressure	91.9 Pa	73 - 156.2 Pa
Static Pressure	0.369 in H2O	0.293 - 0.627 in H2O
Termination	3 Wire Leads	2 Wire Leads, 3 Wire Leads
Voltage - Rated [custom]	48 VDC	48 VDC
Voltage Range [Max]	55.2 VDC	55.2 VDC
Voltage Range [Min]	40.8 VDC	40.8 VDC
Weight	500 g	500 g
Weight	1.1 lbs	1.1 lbs
Width [y]	25.4 mm	25 - 25.4 mm

109E4748 Series

FAN AXIAL 172X25MM 48VDC WIRE

Part	Termination	Bearing Type	Material - Frame	RPM	Power (Watts)	Approval Agency	Air Flow	Air Flow	Lifetime @ Temp.	Width [y]	Voltage - Rated [custom]	Voltage Range [Max]	Voltage Range [Min]	Noise	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Fan Type	Material - Blade	Static Pressure	Static Pressure	Weight	Weight	Features
Sanyo Denki America Inc. 109E4748L402	2 Wire Leads	Ball	Aluminum	2500 RPM	12 W	CSA, TUV, UL	4.54 mł/min	162 CFM	40000 Hrs	25 mm	48 VDC	55.2 VDC	40.8 VDC	48 dB	147 mm	172 mm	Rectangular/Rounded	0.25 A	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.293 in H2O	73 Pa	500 g	1.1 lbs
Sanyo Denki America Inc. 109E4748S402	2 Wire Leads	Ball	Aluminum	3650 RPM	29.8 W	CSA, TUV, UL	6.72 mł/min	240 CFM	40000 Hrs	25 mm	48 VDC	55.2 VDC	40.8 VDC	58 dB(A)	147 mm	172 mm	Rectangular/Rounded	0.62 A	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.627 in H2O	156.2 Pa	500 g	1.1 lbs
Sanyo Denki America Inc. 109E4748H4D01	3 Wire Leads	Ball	Aluminum	3400 RPM	25 W	CSA, TUV, UL	6.33 m³/min	226 CFM	40000 Hrs	25.4 mm	48 VDC	55.2 VDC	40.8 VDC	57 dB	147 mm	172 mm	Rectangular/Rounded	0.52 A	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.542 in H2O	135 Pa	500 g	1.1 lbs	Locked Rotor Sensor
Sanyo Denki America Inc. 109E4748M401	3 Wire Leads	Ball	Aluminum	2800 RPM	15.4 W	CSA, TUV, UL	5.12 mł/min	183 CFM	40000 Hrs	25.4 mm	48 VDC	55.2 VDC	40.8 VDC	51 dB(A)	147 mm	172 mm	Rectangular/Rounded	320 mA	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.369 in H2O	91.9 Pa	500 g	1.1 lbs	Locked Rotor Protection, Speed Sensor (Tach)
Sanyo Denki America Inc. 109E4748L401	3 Wire Leads	Ball	Aluminum	3400 RPM	12 W	CSA, TUV, UL	4.54 mł/min	162 CFM	40000 Hrs	25.4 mm	48 VDC	55.2 VDC	40.8 VDC	48 dB	147 mm	172 mm	Rectangular/Rounded	0.25 A	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.293 in H2O	73 Pa	500 g	1.1 lbs	Locked Rotor Protection, Speed Sensor (Tach)
Sanyo Denki America Inc. 109E4748M402	2 Wire Leads	Ball	Aluminum	2800 RPM	15.4 W	CSA, TUV, UL	5.12 mł/min	183 CFM	40000 Hrs	25 mm	48 VDC	55.2 VDC	40.8 VDC	51 dB(A)	147 mm	172 mm	Rectangular/Rounded	320 mA	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.369 in H2O	91.9 Pa	500 g	1.1 lbs
Sanyo Denki America Inc. 109E4748H401	3 Wire Leads	Ball	Aluminum	3400 RPM	25 W	CSA, TUV, UL	6.33 m³/min	226 CFM	40000 Hrs	25.4 mm	48 VDC	55.2 VDC	40.8 VDC	57 dB	147 mm	172 mm	Rectangular/Rounded	0.52 A	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.542 in H2O	135 Pa	500 g	1.1 lbs	Locked Rotor Protection, Speed Sensor (Tach)
Sanyo Denki America Inc. 109E4748S4D01	3 Wire Leads	Ball	Aluminum	3650 RPM	29.8 W	CSA, TUV, UL	6.72 mł/min	240 CFM	40000 Hrs	25.4 mm	48 VDC	55.2 VDC	40.8 VDC	58 dB(A)	147 mm	172 mm	Rectangular/Rounded	0.62 A	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.627 in H2O	156.2 Pa	500 g	1.1 lbs	Locked Rotor Sensor
Sanyo Denki America Inc. 109E4748H402	2 Wire Leads	Ball	Aluminum	3400 RPM	25 W	CSA, TUV, UL	6.33 m³/min	226 CFM	40000 Hrs	25 mm	48 VDC	55.2 VDC	40.8 VDC	57 dB	147 mm	172 mm	Rectangular/Rounded	0.52 A	60 °C	-20 °C	-20 C	60 °C	Tubeaxial	Plastic	0.542 in H2O	135 Pa	500 g	1.1 lbs
