DS26524GA4
ActiveAnalog Devices Inc./Maxim Integrated
DS26524 QUAD T1/E1/J1 TRANSCVR
Deep-Dive with AI
Search across all available documentation for this part.
DS26524GA4
ActiveAnalog Devices Inc./Maxim Integrated
DS26524 QUAD T1/E1/J1 TRANSCVR
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS26524GA4 | DS26524 Series |
|---|---|---|
| Current - Supply | 450 mA | 260 - 450 mA |
| Function | Framer, Line Interface Unit (LIU) | Line Interface Unit (LIU), Framer, Line Interface Unit (LIU) |
| Interface | J1, T1, E1 | LIU, J1, T1, E1 |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Circuits | 4 | 4 |
| Operating Temperature [Max] | 70 °C | 70 - 85 °C |
| Operating Temperature [Min] | 0 °C | -40 - 0 °C |
| Package / Case | CSPBGA, 256-LBGA | CSBGA, 256-LBGA, CSPBGA |
| Supplier Device Package | 256-CSBGA (17x17) | 256-CSBGA (17x17) |
| Voltage - Supply [Max] | 3.465 V | 3.465 V |
| Voltage - Supply [Min] | 3.135 V | 3.135 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 7 | $ 46.79 | |
DS26524 Series
IC TELECOM INTERFACE 256CSBGA
| Part | Voltage - Supply [Max] | Voltage - Supply [Min] | Mounting Type | Interface | Operating Temperature [Max] | Operating Temperature [Min] | Function | Number of Circuits | Current - Supply | Supplier Device Package | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DS26524GN+ | 3.465 V | 3.135 V | Surface Mount | LIU | 85 °C | -40 °C | Line Interface Unit (LIU) | 4 | 260 mA | 256-CSBGA (17x17) | 256-LBGA, CSBGA |
Analog Devices Inc./Maxim Integrated DS26524G | 3.465 V | 3.135 V | Surface Mount | LIU | 70 °C | 0 °C | Line Interface Unit (LIU) | 4 | 260 mA | 256-CSBGA (17x17) | 256-LBGA, CSBGA |
Analog Devices Inc./Maxim Integrated DS26524GN | 3.465 V | 3.135 V | Surface Mount | LIU | 85 °C | -40 °C | Line Interface Unit (LIU) | 4 | 260 mA | 256-CSBGA (17x17) | 256-LBGA, CSBGA |
Analog Devices Inc./Maxim Integrated DS26524G+ | 3.465 V | 3.135 V | Surface Mount | LIU | 70 °C | 0 °C | Line Interface Unit (LIU) | 4 | 260 mA | 256-CSBGA (17x17) | 256-LBGA, CSBGA |
Analog Devices Inc./Maxim Integrated DS26524GA4 | 3.465 V | 3.135 V | Surface Mount | E1, J1, T1 | 70 °C | 0 °C | Framer, Line Interface Unit (LIU) | 4 | 450 mA | 256-CSBGA (17x17) | 256-LBGA, CSPBGA |
Analog Devices Inc./Maxim Integrated DS26524GA5 | 3.465 V | 3.135 V | Surface Mount | LIU | Line Interface Unit (LIU) | 4 | 260 mA | 256-CSBGA (17x17) | 256-LBGA, CSBGA |
Description
General part information
DS26524 Series
Telecom IC Framer, Line Interface Unit (LIU) 256-CSBGA (17x17)
