PI90LV017AUEX

Obsolete

Diodes Inc

IC DRIVER 1/0 8MSOP

Search across all available documentation for this part.

Obsolete

Diodes Inc

IC DRIVER 1/0 8MSOP

Technical Specifications

Parameters and characteristics for this part

Specification	PI90LV017AUEX

Data Rate	400 Mbps
Mounting Type	Surface Mount
Number of Drivers/Receivers [custom]	0
Number of Drivers/Receivers [custom]	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	8-MSOP, 8-TSSOP
Package / Case	3 mm
Package / Case [custom]	0.118 in
Protocol	LVDS
Supplier Device Package	8-MSOP
Type	Driver
Voltage - Supply [Max]	3.6 V
Voltage - Supply [Min]	3 V

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Max]	Voltage - Supply [Min]	Protocol	Package / Case	Package / Case [custom]	Package / Case	Type	Supplier Device Package	Data Rate	Number of Drivers/Receivers [custom]	Number of Drivers/Receivers [custom]	Mounting Type
Diodes Inc PI90LV017AUEX	85 °C	-40 °C	3.6 V	3 V	LVDS	8-MSOP 8-TSSOP	0.118 in	3 mm	Driver	8-MSOP	400 Mbps	0	1	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

1/0 Driver LVDS 8-MSOP
