302A10019X

Active

Amphenol CONEC

D SUB CONN, RCPT, DE, SOLDER CUP ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Amphenol CONEC

D SUB CONN, RCPT, DE, SOLDER CUP ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	302A10019X

Color	Black
Connector Style	D-Sub
Connector Type	Receptacle, Female Sockets
Contact Finish	Gold
Contact Finish Thickness	8 çin
Contact Finish Thickness	0.203 çm
Contact Form	Stamped
Contact Material	Copper Alloy
Contact Type	Signal
Current Rating (Amps)	7.5 A
Dielectric Material	Polybutylene Terephthalate (PBT), Glass Filled
Flange Feature	Housing/Shell (Unthreaded)
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	9
Number of Rows	2
Shell Size, Connector Layout [custom]	DE, E
Shell Size, Connector Layout [custom]	1
Voltage Rating	125 VDC
Wire Gauge	20 AWG

Part	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Flange Feature	Wire Gauge	Wire Gauge [Max]	Wire Gauge [Min]	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Material Flammability Rating	Contact Type	Dielectric Material	Number of Rows	Number of Positions	Color	Connector Style	Voltage Rating	Contact Finish	Contact Material	Connector Type	Contact Finish Thickness	Contact Finish Thickness	Current Rating (Amps)	Contact Form	Mounting Type	Wire Gauge
Amphenol CONEC 302A10089X	-25 °C	85 °C	IDC Ribbon Cable	Housing/Shell (Unthreaded)	Stranded	28 AWG	26 AWG	DE E	1	UL94 V-0	Signal	Polybutylene Terephthalate (PBT) Glass Filled	2	9	Black	D-Sub	125 VDC	Gold	Phosphor Bronze	Receptacle Female Sockets
Amphenol CONEC 302A10089X-1	-25 °C	85 °C	IDC Ribbon Cable	Housing/Shell (Unthreaded)	Stranded	28 AWG	26 AWG	DE E	1	UL94 V-0	Signal	Polybutylene Terephthalate (PBT) Glass Filled	2	9	Black	D-Sub	125 VDC	Gold	Phosphor Bronze	Receptacle Female Sockets	8 çin	0.203 çm
Amphenol CONEC 302A10019X				Housing/Shell (Unthreaded)				DE E	1	UL94 V-0	Signal	Polybutylene Terephthalate (PBT) Glass Filled	2	9	Black	D-Sub	125 VDC	Gold	Copper Alloy	Receptacle Female Sockets	8 çin	0.203 çm	7.5 A	Stamped	Free Hanging (In-Line)	20 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

9 Position D-Sub Receptacle, Female Sockets Connector
