C3120.41.86
ActivePrysmian Group
CABLE 3COND 18AWG NATURAL
Deep-Dive with AI
Search across all available documentation for this part.
C3120.41.86
ActivePrysmian Group
CABLE 3COND 18AWG NATURAL
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | C3120.41.86 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Conductor Material | Copper, Bare |
| Conductor Strand [custom] | 26 AWG |
| Conductor Strand [custom] | 7 |
| Features | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 4.22 mm |
| Jacket (Insulation) Diameter [diameter] | 0.166 in |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.015 in |
| Jacket (Insulation) Thickness | 0.381 mm |
| Jacket Color | Natural |
| Length | 15.24 m, 304.8 m |
| Length | 1000 ft |
| Length [x] | 30.5 m, 152.4 m |
| Length [x] | 100 ft, 500 ', 50 ft |
| Number of Conductors | 3 |
| Operating Temperature [Max] | 75 ░C |
| Operating Temperature [Min] | 0 °C |
| Ratings | ASTM B-3 |
| Usage | Control, Communication |
| Voltage | 150 V |
| Wire Gauge | 18 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 138.64 | |
| 1 | $ 68.37 | |||
| 1 | $ 436.89 | |||
| 5 | $ 113.43 | |||
| 5 | $ 55.94 | |||
| 5 | $ 388.35 | |||
| 10 | $ 351.94 | |||
| 10 | $ 88.22 | |||
| 10 | $ 43.51 | |||
| 1000 | $ 0.65 | |||
| 2000 | $ 0.62 | |||
| 3000 | $ 0.60 | |||
| 5000 | $ 0.58 | |||
| 7000 | $ 0.56 | |||
| 10000 | $ 0.55 | |||
Description
General part information
C3120 Series
3 Conductor Multi-Conductor Cable Natural 18 AWG 1000.0' (304.8m)
