M80-6810642

Active

Harwin Inc.

BOARD CONNECTOR, 6 CONTACT(S), 2 ROW(S), FEMALE, STRAIGHT, 0.079 INCH PITCH, SURFACE MOUNT TERMINAL, LOCKING, BLACK INSULATOR, SOCKET, LEAD FREE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet M80, M83 Series Spec Sheet +2

M80-6810642

Active

Harwin Inc.

BOARD CONNECTOR, 6 CONTACT(S), 2 ROW(S), FEMALE, STRAIGHT, 0.079 INCH PITCH, SURFACE MOUNT TERMINAL, LOCKING, BLACK INSULATOR, SOCKET, LEAD FREE

Deep-Dive with AI

DocumentsDatasheet M80, M83 Series Spec Sheet +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M80-6810642

Applications	Automotive, Military, General Purpose
Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	12 µin
Contact Finish Thickness - Mating	0.3 µm
Contact Finish Thickness - Post	157.5 Áin
Contact Finish Thickness - Post	4 Ám
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Fastening Type	Locking Ramp
Insulation Color	Black
Insulation Height	5.6 mm
Insulation Height	0.22 in
Insulation Material	Polyamide (PA46), Nylon 4/6, Glass Filled
Mated Stacking Heights	8.45 mm, 7.85 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	6
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Row Spacing - Mating	0.079 in
Row Spacing - Mating	2 mm
Style	Board to Board, Cable
Termination	Solder
Voltage Rating	120 VDC

M80-681 Series

Part	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Post	Material Flammability Rating	Number of Rows	Contact Material	Mounting Type	Insulation Height	Insulation Height	Voltage Rating	Insulation Color	Connector Type	Contact Finish - Mating	Applications	Pitch - Mating [x]	Pitch - Mating [x]	Contact Shape	Insulation Material	Row Spacing - Mating	Row Spacing - Mating	Termination	Contact Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Style	Mated Stacking Heights	Number of Positions	Number of Positions Loaded	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Features	Number of Positions
Harwin Inc. M80-6813445	12 µin	0.3 µm	Gold	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	0.3 µm	12 µin	Board to Board Cable	7.85 mm 8.45 mm	34	All	Locking Ramp	-55 °C	125 °C
Harwin Inc. M80-6811442P	12 µin	0.3 µm	Tin	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm	14	All	Locking Ramp	-55 °C	125 °C	Pick and Place
Harwin Inc. M80-6811242P	12 µin	0.3 µm	Tin	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm	12	All	Locking Ramp	-55 °C	125 °C	Pick and Place
Harwin Inc. M80-6811842P	12 µin	0.3 µm	Tin	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm	18	All	Locking Ramp	-55 °C	125 °C	Pick and Place
Harwin Inc. M80-6812001P	12 µin	0.3 µm	Tin-Lead	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm	20	All	Locking Ramp	-55 °C	125 °C	Pick and Place
Harwin Inc. M80-6811642P	12 µin	0.3 µm	Tin	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm		All	Locking Ramp	-55 °C	125 °C	Pick and Place	16
Harwin Inc. M80-6811445	12 µin	0.3 µm	Gold	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	0.3 µm	12 µin	Board to Board Cable	7.85 mm 8.45 mm	14	All	Locking Ramp	-55 °C	125 °C
Harwin Inc. M80-6810642	12 µin	0.3 µm	Tin	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm	6	All	Locking Ramp	-55 °C	125 °C
Harwin Inc. M80-6813442P	12 µin	0.3 µm	Tin	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm	34	All	Locking Ramp	-55 °C	125 °C	Pick and Place
Harwin Inc. M80-6811042P	12 µin	0.3 µm	Tin	UL94 V-0	2	Beryllium Copper	Surface Mount	5.6 mm	0.22 in	120 VDC	Black	Receptacle	Gold	Automotive General Purpose Military	0.079 in	2 mm	Circular	Glass Filled Nylon 4/6 Polyamide (PA46)	0.079 in	2 mm	Solder	Female Socket	4 Ám	157.5 Áin	Board to Board Cable	7.85 mm 8.45 mm	10	All	Locking Ramp	-55 °C	125 °C	Pick and Place

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 8.30
		26	$ 7.03
		104	$ 6.67
		520	$ 5.59
		1014	$ 4.94
Newark	Each	50	$ 8.04
		100	$ 7.50
		250	$ 6.93
		500	$ 6.40
		1000	$ 5.86
		2500	$ 5.29

Description

General part information

M80-681 Series

6 Position Receptacle Connector 0.079" (2.00mm) Surface Mount Gold

Documents

Technical documentation and resources

Datasheet

M80, M83 Series Spec Sheet

Datasheet

M80-6810642
