APT2X41DC120J

Active

Microsemi Corporation

DIODE MOD SIC 1200V 40A SOT227

Search across all available documentation for this part.

Active

Microsemi Corporation

DIODE MOD SIC 1200V 40A SOT227

Technical Specifications

Parameters and characteristics for this part

Specification	APT2X41DC120J

Current - Average Rectified (Io) (per Diode)	40 A
Current - Reverse Leakage @ Vr	800 µA
Diode Configuration	2 Independent
Mounting Type	Chassis Mount
Package / Case	ISOTOP
Reverse Recovery Time (trr)	0 ns
Speed	No Recovery Time
Supplier Device Package	SOT-227
Technology	SiC (Silicon Carbide) Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	1.2 kV
Voltage - Forward (Vf) (Max) @ If	1.8 V

Part	Technology	Current - Average Rectified (Io) (per Diode)	Current - Reverse Leakage @ Vr	Package / Case	Voltage - Forward (Vf) (Max) @ If	Supplier Device Package	Voltage - DC Reverse (Vr) (Max) [Max]	Mounting Type	Speed	Reverse Recovery Time (trr)	Diode Configuration
Microsemi Corporation APT2X41DC120J	SiC (Silicon Carbide) Schottky	40 A	800 µA	ISOTOP	1.8 V	SOT-227	1.2 kV	Chassis Mount	No Recovery Time	0 ns	2 Independent
Microsemi Corporation APT2X41DC60J	SiC (Silicon Carbide) Schottky	40 A	800 µA	ISOTOP	1.8 V	SOT-227	600 V	Chassis Mount	No Recovery Time	0 ns	2 Independent

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Diode Array 2 Independent 1200 V 40A Chassis Mount ISOTOP
