SRP5030TA-5R6M

Active

Bourns Inc.

POWER INDUCTOR (SMD), 5.6 ΜH, 4.25 A, SHIELDED, 4.5 A, SRP5030TA SERIES

Search across all available documentation for this part.

Active

Bourns Inc.

POWER INDUCTOR (SMD), 5.6 ΜH, 4.25 A, SHIELDED, 4.5 A, SRP5030TA SERIES

Technical Specifications

Parameters and characteristics for this part

Part	Package / Case	Type	Current - Saturation (Isat)	Height - Seated (Max)	Height - Seated (Max) [Max]	Q @ Freq	Shielding	Ratings	Frequency - Self Resonant	Inductance	Mounting Type	Inductance Frequency - Test	Tolerance	DC Resistance (DCR) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Material - Core	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]
Bourns Inc. SRP5030TA-5R6M	Nonstandard	Drum Core Wirewound	4.5 A	3 mm	0.118 in	15 100 kHz	Shielded	AEC-Q200	21 MHz	5.6 µH	Surface Mount	100 kHz	20 %	63 mOhm	5.2 mm	5.7 mm	0.205 "	0.224 in	Carbonyl Powder
Bourns Inc. SRP5030TA-3R6M	Nonstandard	Drum Core Wirewound	7 A	3 mm	0.118 in	15 100 kHz	Shielded	AEC-Q200	29 MHz	3.6 µH	Surface Mount	100 kHz	20 %	54 mOhm			0.205 " 5.2 mm	0.209 " 5.3 mm	Carbonyl Powder	4.9 A	-55 °C	150 °C
Bourns Inc. SRP5030TA-R22M	Nonstandard	Drum Core Wirewound	21 A	3 mm	0.118 in	5 100 kHz	Shielded	AEC-Q200	155 MHz	220 nH	Surface Mount	100 kHz	20 %	4.4 mOhm	5.2 mm	5.7 mm	0.205 "	0.224 in	Carbonyl Powder	15.5 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5.6 µH Shielded Drum Core, Wirewound Inductor 4.25 A 63mOhm Max Nonstandard
