LPV-150-48

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC 48V 3.2A

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC 48V 3.2A

Technical Specifications

Parameters and characteristics for this part

Part	Topology	Type	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Output	Termination Style	Current - Output (Max) [Max]	Ratings	Power (Watts)	Voltage - Isolation	Efficiency	Voltage - Input (Min) [Min]	Voltage - Input (Max) [Max]	Features	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Approval Agency
MEAN WELL USA Inc. LPV-150-48	AC DC Converter	Constant Voltage	7.52 in	37.5 mm	63 mm	191 mm	1.48 "	2.48 in	48 V	Wire Leads	3.2 A	IP67	154 W	3000 V	90 %	180 VAC	305 VAC	OCP OTP OVP SCP	1	65 °C	-25 °C	Chassis Mount	CE cURus
MEAN WELL USA Inc. LPV-150-12	AC DC Converter	Constant Voltage	7.52 in	37.5 mm	63 mm	191 mm	1.48 "	2.48 in	12 V	Wire Leads	10 A	IP67	120 W	3000 V	87 %	180 VAC	305 VAC	OCP OTP OVP SCP	1	65 °C	-25 °C	Chassis Mount	CE cURus
MEAN WELL USA Inc. LPV-150-15	AC DC Converter	Constant Voltage	7.52 in	37.5 mm	63 mm	191 mm	1.48 "	2.48 in	15 VDC	Wire Leads	8 A	IP67	120 W	3000 V	88 %	180 VAC	305 VAC	OCP OTP OVP SCP	1	65 °C	-25 °C	Chassis Mount	CE cURus
MEAN WELL USA Inc. LPV-150-36	AC DC Converter	Constant Voltage	7.52 in	37.5 mm	63 mm	191 mm	1.48 "	2.48 in	36 V	Wire Leads	4.2 A	IP67	151 W	3000 V	89 %	180 VAC	305 VAC	OCP OTP OVP SCP	1	65 °C	-25 °C	Chassis Mount	CE cURus

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3.2A 48V Constant Voltage LED Driver AC DC Converter Topology 1 Output

Technical documentation and resources
