2834423

Active

Phoenix Contact

RELAY GEN PURPOSE SPDT 10A 120V

Deep-Dive with AI

Search across all available documentation for this part.

2834423

Active

Phoenix Contact

RELAY GEN PURPOSE SPDT 10A 120V

Deep-Dive with AI

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

28344 Series

General Purpose Relay SPDT (1 Form C) 120VAC Coil DIN Rail

Documents

Technical documentation and resources

No documents available

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	2834423	28344 Series

Coil Current	7 mA	5.5 - 26 mA
Coil Resistance	17.1 kOhms	17.1 - 1263 Ohms
Coil Type	Non Latching	Non Latching
Coil Voltage	120 VAC	24 - 230 VAC
Contact Form	SPDT (1 Form C)	DPDT (2 Form C), SPDT (1 Form C)
Contact Material	Silver Nickel (AgNi)	Silver Nickel (AgNi), Gold (Au)
Contact Rating (Current)	10 A	8 - 10 A
Features	Lighted Indicator, Varistor, Socket Included	Lighted Indicator, Varistor, Socket Included, Diode
Mounting Type	DIN Rail	DIN Rail
Operate Time	12 ms	8 - 12 ms
Operating Temperature [Max]	60 °C	60 °C
Operating Temperature [Min]	-25 °C	-25 °C
Relay Type	General Purpose	General Purpose
Release Time	16 ms	10 - 22 ms
Switching Voltage	250 VAC, 250 VDC	30 - 250 VAC
Termination Style	Spring Terminal	Screw Terminal, Spring Terminal

28344 Series

RELAY GEN PURPOSE DPDT 8A 24V

Part	Coil Type	Contact Rating (Current)	Termination Style	Contact Form	Switching Voltage	Operate Time	Relay Type	Mounting Type	Features	Coil Voltage	Coil Current	Coil Resistance	Operating Temperature [Min]	Operating Temperature [Max]	Release Time	Contact Material
Phoenix Contact 2834494	Non Latching	8 A	Screw Terminal	DPDT (2 Form C)	250 VAC, 250 VDC	12 ms	General Purpose	DIN Rail	Lighted Indicator, Socket Included, Varistor	24 VAC	26 mA	923 Ohms	-25 °C	60 °C	14 ms	Silver Nickel (AgNi)
Phoenix Contact 2834436	Non Latching	10 A	Spring Terminal	SPDT (1 Form C)	250 VAC, 250 VDC	12 ms	General Purpose	DIN Rail	Lighted Indicator, Varistor	230 VAC	5.5 mA	41.82 kOhms	-25 °C	60 °C	22 ms	Silver Nickel (AgNi)
Phoenix Contact 2834478	Non Latching	10 A	Spring Terminal	SPDT (1 Form C)	30 VAC, 36 VDC	12 ms	General Purpose	DIN Rail	Socket Included, Varistor	230 VAC	5.5 mA	41.8 kOhms	-25 °C	60 °C	22 ms	Gold (Au), Silver Nickel (AgNi)
Phoenix Contact 2834423	Non Latching	10 A	Spring Terminal	SPDT (1 Form C)	250 VAC, 250 VDC	12 ms	General Purpose	DIN Rail	Lighted Indicator, Socket Included, Varistor	120 VAC	7 mA	17.1 kOhms	-25 °C	60 °C	16 ms	Silver Nickel (AgNi)
Phoenix Contact 2834465	Non Latching	10 A	Spring Terminal	SPDT (1 Form C)	250 VAC, 250 VDC	12 ms	General Purpose	DIN Rail	Lighted Indicator, Varistor	120 VAC	7 mA	17.14 kOhms	-25 °C	60 °C	16 ms	Gold (Au), Silver Nickel (AgNi)
Phoenix Contact 2834407	Non Latching	10 A	Spring Terminal	SPDT (1 Form C)	250 VAC, 250 VDC	8 ms	General Purpose	DIN Rail	Diode, Lighted Indicator, Socket Included	24 VDC	19 mA	1263 Ohms	-25 °C	60 °C	10 ms	Silver Nickel (AgNi)
