ZUW31212-G

Obsolete

Cosel USA, Inc.

DC DC CONVERTER +/-12V 24V 3.1W

Search across all available documentation for this part.

Obsolete

Cosel USA, Inc.

DC DC CONVERTER +/-12V 24V 3.1W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER +/-12V 24V 3.1W

Part	Voltage - Output 2	Voltage - Input (Max) [Max]	Voltage - Isolation	Voltage - Output 1	Mounting Type	Power (Watts)	Number of Outputs	Type	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Applications	Current - Output (Max)	Current - Output (Max)	Voltage - Input (Min) [Min]	Efficiency	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]
Cosel USA, Inc. ZUW31212-G	-12 V	18 V	500 V	12 V	Through Hole	3.1 W	2	Isolated Module	0.28 "	1.38 "	0.91 in	35 mm	7 mm	23 mm	ITE (Commercial)	130 mA	130 mA	9 V	74 %	5-DIP Module	-20 °C	71 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 2 Output 12V -12V 130mA, 130mA 9V - 18V Input
