23C11D-40ML5

Active

Rosenberger

CONN MINICOAX 8PORT ST 50OHM SMD

Search across all available documentation for this part.

Active

Rosenberger

CONN MINICOAX 8PORT ST 50OHM SMD

Technical Specifications

Parameters and characteristics for this part

Specification	23C11D-40ML5

Body Finish	Gold
Body Material	Brass
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Connector Style	Miniature Coaxial
Connector Type	Plug, Male Pin (4), Jack, Female Socket (4)
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Snap-On
Frequency - Max [Max]	20 GHz
Housing Color	Gold
Impedance	50 Ohms
Mating Cycles	500
Mounting Type	Surface Mount
Number of Ports	8
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Shield Termination	Solder
Voltage Rating	500 V

Part	Connector Type	Connector Style	Contact Termination	Center Contact Material	Voltage Rating	Housing Color	Dielectric Material	Frequency - Max [Max]	Body Material	Operating Temperature [Max]	Operating Temperature [Min]	Body Finish	Shield Termination	Mating Cycles	Impedance	Center Contact Plating	Number of Ports	Mounting Type	Fastening Type
Rosenberger 23C11D-40ML5	Jack Female Socket (4) Plug Male Pin (4)	Miniature Coaxial	Solder	Beryllium Copper	500 V	Gold	Polytetrafluoroethylene (PTFE)	20 GHz	Brass	125 °C	-40 °C	Gold	Solder	500	50 Ohms	Gold	8	Surface Mount	Snap-On

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Miniature Coaxial Connector Jack, Female Socket (4); Plug, Male Pin (4) 50 Ohms Surface Mount Solder
