KUP-17D19-24

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 4PDT 10A 24V

Search across all available documentation for this part.

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 4PDT 10A 24V

Technical Specifications

Parameters and characteristics for this part

Part	Relay Type	Contact Material	Mounting Type	Coil Current	Switching Voltage	Coil Type	Coil Resistance	Operating Temperature [Max] [custom]	Operating Temperature [Min] [custom]	Contact Form	Operate Time	Approval Agency	Must Operate Voltage	Release Time	Coil Insulation	Load - Max Switching [Max]	Coil Voltage	Termination Style	Contact Rating (Current)	Operating Temperature [Min]	Operating Temperature [Max]
TE Connectivity Potter & Brumfield Relays KUP-17A55-120	General Purpose	Silver Cadmium Oxide (AgCdO)	Chassis Mount	24 mA	240 VAC	Non Latching	1.7 kOhms	45 °C	-45 °C	4PDT (4 Form C)	15 ms	CSA UR	102 VAC	10 ms	Class B	2400 VA	120 VAC	Quick Connect - 0.187" (4.7mm)	10 A
TE Connectivity Potter & Brumfield Relays KUP-17D19-48	General Purpose	Silver Cadmium Oxide (AgCdO)	Socketable	38.4 mA	240 VAC	Non Latching	1250 Ohms			4PDT (4 Form C)	15 ms	CSA UR	36 VDC	10 ms	Class B	2400 VA	48 VDC		10 A	-45 °C	50 °C
TE Connectivity Potter & Brumfield Relays KUP-17A19-120	General Purpose	Silver Cadmium Oxide (AgCdO)	Socketable	24 mA	240 VAC	Non Latching	1.7 kOhms	45 °C	-45 °C	4PDT (4 Form C)	15 ms	CSA UR	102 VAC	10 ms	Class B	2400 VA	120 VAC		10 A
TE Connectivity Potter & Brumfield Relays KUP-17D19-24	General Purpose	Silver Cadmium Oxide (AgCdO)	Socketable	75 mA	240 VAC	Non Latching	320 Ohms			4PDT (4 Form C)	15 ms	CSA UR	18 VDC	10 ms	Class B	2400 VA	24 VDC		10 A	-45 °C	50 °C
TE Connectivity Potter & Brumfield Relays KUP-17A19-24	General Purpose	Silver Cadmium Oxide (AgCdO)	Socketable	115 mA	240 VAC	Non Latching	72 Ohms	45 °C	-45 °C	4PDT (4 Form C)	15 ms	CSA UR		10 ms	Class B	2400 VA	24 VAC		10 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay 4PDT (4 Form C) 24VDC Coil Socketable
