H2UE3P1D2G0100

Active

Unictron Technologies Corporation

LTE/4G FULL BAND 698-960 1710-26

Search across all available documentation for this part.

Active

Unictron Technologies Corporation

LTE/4G FULL BAND 698-960 1710-26

Technical Specifications

Parameters and characteristics for this part

Specification	H2UE3P1D2G0100

Antenna Type	Chip
Applications	2G, CDMA, GPRS, UMTS, 4G, 3G, LTE, HSDPA, WCDMA, DCS, GSM, PCS, EDGE
Frequency (Center/Band)	748 MHz, 2.35 GHz, 892 MHz, 2.59 GHz, 1.94 GHz
Frequency Group	Wide Band
Frequency Range [Max]	960 MHz, 2.4 GHz, 2.69 GHz, 2.17 GHz, 798 MHz
Frequency Range [Min]	1.71 GHz, 2.3 GHz, 2.49 GHz, 824 MHz, 698 MHz
Gain	4.2 dBi, 3.2 dBi, 1.4 dBi, 1.1 dBi, 3.8 dBi
Height (Max) [Max]	6 mm
Height (Max) [Max]	0.236 in
Mounting Type	Surface Mount
Number of Bands [custom]	5
Power - Max [Max]	2 W
RF Family/Standard	Cellular
Termination	Solder
VSWR	3

LTE/4G FULL BAND 698-960 1710-26

Part	Gain	Frequency Group	Mounting Type	VSWR	Applications	Frequency (Center/Band)	Termination	Number of Bands [custom]	Power - Max [Max]	Height (Max) [Max]	Height (Max) [Max]	Antenna Type	Frequency Range [Min]	Frequency Range [Max]	RF Family/Standard
Unictron Technologies Corporation H2UE3P1D2G0100	1.1 dBi, 1.4 dBi, 3.2 dBi, 3.8 dBi, 4.2 dBi	Wide Band	Surface Mount	3	2G, 3G, 4G, CDMA, DCS, EDGE, GPRS, GSM, HSDPA, LTE, PCS, UMTS, WCDMA	1.94 GHz, 2.35 GHz, 2.59 GHz, 748 MHz, 892 MHz	Solder	5	2 W	6 mm	0.236 in	Chip	1.71 GHz, 2.3 GHz, 2.49 GHz, 698 MHz, 824 MHz	2.17 GHz, 2.4 GHz, 2.69 GHz, 798 MHz, 960 MHz	Cellular

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF ANTENNA 2G, 3G, 4G, CDMA, DCS, EDGE, GPRS, GSM, HSDPA, LTE, PCS, UMTS, WCDMA Chip Solder Surface Mount
