C14610B0031023

Active

Amphenol Tuchel Industrial

INSERT FEMALE 3+2POS+1GND SCREW

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

INSERT FEMALE 3+2POS+1GND SCREW

Technical Specifications

Parameters and characteristics for this part

Specification	C14610B0031023

Color	Gray
Contact Finish	Silver
Contact Material	Brass
Current Rating (Amps)	10 A
Gender	Female
Material Flammability Rating	UL94 V-0
Number of Positions [custom]	3
Number of Positions [custom]	Ground
Number of Positions [custom]	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Size	E10
Termination Style	Screw
Voltage Rating	600 V

Part	Contact Material	Gender	Color	Termination Style	Size	Voltage Rating	Material Flammability Rating	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions [custom]	Number of Positions [custom]	Number of Positions [custom]	Current Rating (Amps)	Contact Finish	Connector Type
Amphenol Tuchel Industrial C14610B0031023	Brass	Female	Gray	Screw	E10	600 V	UL94 V-0	125 °C	-40 °C	3	Ground	2	10 A	Silver
Amphenol Tuchel Industrial C14610B00350015		Female	Black	Crimp		400 V	UL94 V-0	125 °C	-40 °C						Module without Contacts

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 14.82

General part information

Female Insert Gray 3+2+Ground Position Screw

Technical documentation and resources
