52-272.025

Active

EAO

ROTARY SWITCH, 2 POSITION, 90 °, 5 A, 250 V, 51 SERIES

Search across all available documentation for this part.

Active

EAO

ROTARY SWITCH, 2 POSITION, 90 °, 5 A, 250 V, 51 SERIES

Technical Specifications

Parameters and characteristics for this part

Specification	52-272.025

Approval Agency	CB, CSA, UL, CE
Circuit	4PST-2NO/2NC
Current Rating (Amps)	5 A
Illumination	Illuminated
Ingress Protection	IP65 - Dust Tight, Water Resistant
Mechanical Life	1000000 Cycles
Number of Positions	2
Operating Temperature [Max]	55 °C
Operating Temperature [Min]	-25 °C
Panel Cutout Dimensions [diameter]	16.2 mm
Switch Function	On-Off, Off-On
Termination Style	Solder Lug
Type	Standard
Voltage Rating - AC	250 V

ROTARY SWITCH, 2 POSITION, 90 °, 5 A, 250 V, 51 SERIES

Part	Approval Agency	Termination Style	Switch Function	Panel Cutout Dimensions [diameter]	Current Rating (Amps)	Mechanical Life	Voltage Rating - AC	Ingress Protection	Circuit	Type	Number of Positions	Illumination	Operating Temperature [Max]	Operating Temperature [Min]
EAO 52-272.025	CB, CE, CSA, UL	Solder Lug	Off-On, On-Off	16.2 mm	5 A	1000000 Cycles	250 V	IP65 - Dust Tight, Water Resistant	4PST-2NO/2NC	Standard	2	Illuminated	55 °C	-25 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Selector Switch 2 Position 4PST-2NO/2NC 5A (AC) 250 V Panel Mount
