TS121SZQ2
ActiveELECTROSWITCH
SWITCH TOGGLE SPDT 6A 125V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TS121SZQ2
ActiveELECTROSWITCH
SWITCH TOGGLE SPDT 6A 125V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TS121SZQ2 |
|---|---|
| Actuator Length [x] | 10.87 mm |
| Actuator Type | Knurled Cap |
| Circuit | SPDT |
| Current Rating (Amps) | 6 A |
| Electrical Life | 60000 Cycles |
| Features | Black Actuator |
| Illumination | Non-Illuminated |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -30 ░C |
| Panel Cutout Dimensions [diameter] | 17.53 mm |
| Switch Function | On-Off-On |
| Termination Style | Solder Lug |
| Voltage Rating - AC | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 23.16 | |
| 10 | $ 21.03 | |||
| 25 | $ 20.09 | |||
| 50 | $ 19.03 | |||
| 100 | $ 18.32 | |||
| 250 | $ 17.13 | |||
| 500 | $ 14.63 | |||
Description
General part information
TS121 Series
Toggle Switch SPDT Panel Mount
