ST123D00

Active

E-Switch

SWITCH TOGGLE SPDT 20A 125V

Search across all available documentation for this part.

Active

E-Switch

SWITCH TOGGLE SPDT 20A 125V

Technical Specifications

Parameters and characteristics for this part

Specification	ST123D00

Actuator Length [x]	19.5 mm
Actuator Material	Brass, Nickel Plated
Actuator Type	Standard Round
Bushing Thread	M12
Bushing Thread	1 x 1
Circuit	SPDT
Current Rating (Amps)	20 A
Electrical Life	6000 Cycles
Illumination	Non-Illuminated
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	0 °C
Panel Cutout Dimensions [diameter]	12 mm
Switch Function	On-On
Termination Style	Solder Lug
Voltage Rating - AC	125 V

Part	Circuit	Operating Temperature [Min]	Operating Temperature [Max]	Illumination	Voltage Rating - AC	Bushing Thread	Bushing Thread	Current Rating (Amps)	Actuator Type	Electrical Life	Actuator Length [x]	Switch Function	Panel Cutout Dimensions [diameter]	Actuator Material	Termination Style
E-Switch ST123D00	SPDT	0 °C	85 °C	Non-Illuminated	125 V	M12	1 x 1	20 A	Standard Round	6000 Cycles	19.5 mm	On-On	12 mm	Brass Nickel Plated	Solder Lug

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1000	$ 4.45

General part information

Toggle Switch SPDT Panel Mount

Technical documentation and resources

No documents available
