DTH1206D

Active

Diodes Inc

DIODE GEN PURP 600V 12A TO220AC

Search across all available documentation for this part.

Active

Diodes Inc

DIODE GEN PURP 600V 12A TO220AC

Technical Specifications

Parameters and characteristics for this part

Specification	DTH1206D

Current - Average Rectified (Io)	12 A
Current - Reverse Leakage @ Vr	45 µA
Mounting Type	Through Hole
Operating Temperature - Junction [Max]	150 °C
Operating Temperature - Junction [Min]	-55 °C
Package / Case	TO-220-2
Reverse Recovery Time (trr)	30 ns
Speed	200 mA, 500 ns
Supplier Device Package	TO220AC (Type WX)
Technology	Standard
Voltage - DC Reverse (Vr) (Max) [Max]	600 V
Voltage - Forward (Vf) (Max) @ If	2.9 V

HYPER-FAST EPITAXIAL RECTIFIER

Part	Mounting Type	Reverse Recovery Time (trr)	Current - Average Rectified (Io)	Speed	Voltage - DC Reverse (Vr) (Max) [Max]	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Technology	Voltage - Forward (Vf) (Max) @ If	Package / Case	Supplier Device Package	Current - Reverse Leakage @ Vr
Diodes Inc DTH1206D	Through Hole	30 ns	12 A	200 mA 500 ns	600 V	150 °C	-55 °C	Standard	2.9 V	TO-220-2	TO220AC (Type WX)	45 µA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Suitable for industrial power supplies, motor controls, and similar mission-critical systems; snubber, bootstrap, and demagnetization applications.
