89134-0001

Active

3M (TC)

CONN RCPT 34P IDC 26-28AWG GOLD

Search across all available documentation for this part.

Active

3M (TC)

CONN RCPT 34P IDC 26-28AWG GOLD

Technical Specifications

Parameters and characteristics for this part

Part	Wire Type	Contact Finish Thickness	Contact Finish Thickness	Mounting Type	Connector Type	Number of Positions	Features	Contact Finish	Number of Rows	Color	Contact Type	Pitch [x]	Pitch [x]	Row Spacing [x]	Row Spacing	Cable Termination
3M (TC) 89134-0001HA	Ribbon Cable	0.76 Ám	30 Áin	Free Hanging (In-Line)	Receptacle	34	Feed Through	Gold	2	Gray	Female Socket	2.54 mm	0.1 in	0.1 in	2.54 mm	IDC
3M (TC) 89134-0001	Ribbon Cable	0.76 Ám	30 Áin	Free Hanging (In-Line)	Receptacle	34	Feed Through	Gold	2	Gray	Female Socket	2.54 mm	0.1 in	0.1 in	2.54 mm	IDC
3M (TC) 89134-0101	Ribbon Cable	0.76 Ám	30 Áin	Free Hanging (In-Line)	Receptacle	34	Feed Through Polarizing Key	Gold	2	Gray	Female Socket	2.54 mm	0.1 in	0.1 in	2.54 mm	IDC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

34 Position Rectangular Receptacle Connector IDC Gold 26-28 AWG
