DP83826EVM

Active

Texas Instruments

DP83826 EVM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

DP83826EVM

Active

Texas Instruments

DP83826 EVM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	DP83826EVM	DP83826 Series

Current - Supply	-	55 mA
Function	Ethernet	Controller, MAC Controller, Ethernet
Interface	-	MII, RMII
Operating Temperature	-	85 - 105 °C
Operating Temperature	-	-40 °C
Package / Case	-	32-VFQFN Exposed Pad
Protocol	-	Ethernet
Standards	-	10/100 Base-T/TX PHY, IEEE 802.3
Supplied Contents	Board(s)	Board(s)
Supplier Device Package	-	32-VQFN (5x5)
Type	Interface	Interface
Voltage - Supply	-	1.62 - 3 V
Voltage - Supply	-	1.98 - 3.6 V

DP83826 Series

Low latency 10/100-Mbps PHY with MII interface and enhanced mode

Part	Function	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Min]	Voltage - Supply [Max]	Supplier Device Package	Standards	Protocol	Current - Supply	Interface	Type	Supplied Contents
Texas Instruments DP83826ERHBR	Controller	32-VFQFN Exposed Pad	105 °C	-40 °C	1.62 V, 3 V	1.98 V, 3.6 V	32-VQFN (5x5)	10/100 Base-T/TX PHY	Ethernet	55 mA	MII, RMII
Texas Instruments DP83826IRHBT	MAC Controller	32-VFQFN Exposed Pad	85 °C	-40 °C	1.62 V, 3 V	1.98 V, 3.6 V	32-VQFN (5x5)	10/100 Base-T/TX PHY, IEEE 802.3	Ethernet	55 mA	MII, RMII
Texas Instruments DP83826EVM	Ethernet											Interface	Board(s)
Texas Instruments DP83826IRHBR	MAC Controller	32-VFQFN Exposed Pad	85 °C	-40 °C	1.62 V, 3 V	1.98 V, 3.6 V	32-VQFN (5x5)	10/100 Base-T/TX PHY, IEEE 802.3	Ethernet	55 mA	MII, RMII

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 178.80

Description

General part information

DP83826 Series

The DP83826 offers low and deterministic latency, low power and supports 10BASE-Te, 100BASE-TX Ethernet protocols to meet stringent requirements in real-time industrial Ethernet systems. The device includes hardware bootstraps to achieve fast link-up time, fast link-drop detection modes and dedicated reference CLKOUT to clock synchronize other modules on the systems.

The two configurable modes are BASIC standard Ethernet mode that uses a common Ethernet pinout, and ENHANCED Ethernet mode which supports standard Ethernet mode and multiple industrial Ethernet fieldbus applications with the additional features and hardware bootstraps configuration.
