UF12B23-BTLR

Active

Mechatronics Fan Group

FAN AXIAL 120X38MM 230VAC TERM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet AC Axial Part Numbering Guide

UF12B23-BTLR

Active

Mechatronics Fan Group

FAN AXIAL 120X38MM 230VAC TERM

Deep-Dive with AI

DocumentsDatasheet AC Axial Part Numbering Guide

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	60	$ 17.79

Description

General part information

UF12B Series

Fan Tubeaxial 230VAC Square - 120mm L x 120mm H Ball 53.0 CFM (1.48mł/min) 2 Terminals

Documents

Technical documentation and resources

Datasheet

AC Axial Part Numbering Guide

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	UF12B23-BTLR	UF12B Series

Air Flow	1.48 mł/min	1.48 - 2.1 mł/min
Air Flow	53 CFM	53 - 75 CFM
Approval Agency	CE, cUL, TUV, UL	CE, cUL, TUV, UL
Bearing Type	Ball	Ball
Current Rating (Amps)	60 mA	60 - 150 mA
Fan Type	Tubeaxial	Tubeaxial
Features	-	Conformal Coating
Lifetime @ Temp.	50000 Hrs	50000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)
Material - Frame	Aluminum	Aluminum
Noise	33 dB(A)	33 - 42 dB(A)
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-40 °C	-40 °C
Operating Temperature [Min]	-40 °C	-40 °C
Power (Watts)	14 Watts	11 - 14 W
RPM	2000 RPM	2000 - 2900 RPM
Size / Dimension [x]	120 mm	120 mm
Size / Dimension [y]	120 mm	120 mm
Static Pressure	0.11 in H2O	0.11 - 0.24 in H2O
Static Pressure	27.4 Pa	27.4 - 59.8 Pa
Termination	2 Terminals	2 Wire Leads, 2 Terminals
Voltage - Rated	230 VAC	115 - 230 VAC
Weight	0.725 lb	0.725 lb
Weight	328.85 g	328.85 g
Width [y]	25 mm	25 mm

UF12B Series

FAN AXIAL 120X38MM 115VAC WIRE

Part	Voltage - Rated	Lifetime @ Temp.	Power (Watts)	Air Flow	Air Flow	Weight	Weight	Approval Agency	Current Rating (Amps)	Bearing Type	RPM	Material - Blade	Material - Frame	Fan Type	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [x]	Static Pressure	Static Pressure	Noise	Termination	Width [y]	Features
Mechatronics Fan Group UF12B12-BWLR	115 VAC	50000 Hrs	11 W	53 CFM	1.48 mł/min	0.725 lb	328.85 g	CE, cUL, TUV, UL	110 mA	Ball	2000 RPM	Polybutylene Terephthalate (PBT)	Aluminum	Tubeaxial	70 °C	70 °C	-40 °C	-40 °C	120 mm	120 mm	0.11 in H2O	27.4 Pa	33 dB(A)	2 Wire Leads	25 mm
Mechatronics Fan Group UF12B12-BTLR	115 VAC	50000 Hrs	11 W	53 CFM	1.48 mł/min	0.725 lb	328.85 g	CE, cUL, TUV, UL	110 mA	Ball	2000 RPM	Polybutylene Terephthalate (PBT)	Aluminum	Tubeaxial	70 °C	70 °C	-40 °C	-40 °C	120 mm	120 mm	0.11 in H2O	27.4 Pa	33 dB(A)	2 Terminals	25 mm
Mechatronics Fan Group UF12B23-BTHR	230 VAC	50000 Hrs	14 Watts	75 CFM	2.1 m³/min	0.725 lb	328.85 g	CE, cUL, TUV, UL	70 mA	Ball	2900 RPM	Polybutylene Terephthalate (PBT)	Aluminum	Tubeaxial	70 °C	70 °C	-40 °C	-40 °C	120 mm	120 mm	0.24 in H2O	59.8 Pa	42 dB	2 Terminals	25 mm
Mechatronics Fan Group UF12B23-BTLR	230 VAC	50000 Hrs	14 Watts	53 CFM	1.48 mł/min	0.725 lb	328.85 g	CE, cUL, TUV, UL	60 mA	Ball	2000 RPM	Polybutylene Terephthalate (PBT)	Aluminum	Tubeaxial	70 °C	70 °C	-40 °C	-40 °C	120 mm	120 mm	0.11 in H2O	27.4 Pa	33 dB(A)	2 Terminals	25 mm
Mechatronics Fan Group UF12B12-BTHR	115 VAC	50000 Hrs	11 W	75 CFM	2.1 m³/min	0.725 lb	328.85 g	CE, cUL, TUV, UL	120 mA	Ball	2900 RPM	Polybutylene Terephthalate (PBT)	Aluminum	Tubeaxial	70 °C	70 °C	-40 °C	-40 °C	120 mm	120 mm	0.24 in H2O	59.8 Pa	42 dB	2 Terminals	25 mm
Mechatronics Fan Group UF12B12-BWHR-CC	115 VAC	50000 Hrs	11 W	75 CFM	2.1 m³/min	0.725 lb	328.85 g	CE, cUL, TUV, UL	150 mA	Ball	2900 RPM	Polybutylene Terephthalate (PBT)	Aluminum	Tubeaxial	70 °C	70 °C	-40 °C	-40 °C	120 mm	120 mm	0.24 in H2O	59.8 Pa	42 dB	2 Wire Leads	25 mm	Conformal Coating
