LDQ-M283RI

Active

Lumex Opto/Components Inc.

DISP 7SEG 0.28" QUAD YLW 12DIP

Deep-Dive with AI

Search across all available documentation for this part.

LDQ-M283RI

Active

Lumex Opto/Components Inc.

DISP 7SEG 0.28" QUAD YLW 12DIP

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	LDQ-M283RI

Color	Yellow
Common Pin	Common Anode
Current - Test	10 mA
Digit/Alpha Size	7 mm
Digit/Alpha Size	0.28 in
Display Type	7-Segment
Millicandela Rating	3 mcd
Number of Characters	4
Package / Case	12-DIP
Package / Case	7.62 mm
Package / Case	0.3 in
Power Dissipation (Max) [Max]	105 mW
Size / Dimension [x]	0.402 in
Size / Dimension [x]	10.2 mm
Size / Dimension [y]	32.2 mm
Size / Dimension [y]	1.268 in
Size / Dimension [z]	5.8 mm
Size / Dimension [z]	0.228 "
Voltage - Forward (Vf) (Typ)	2.1 V
Wavelength - Peak	585 nm

LDQ-M283 Series

DISP 7SEG 0.28" QUAD YLW 12DIP

Part	Color	Package / Case	Package / Case	Package / Case	Current - Test	Power Dissipation (Max) [Max]	Digit/Alpha Size	Digit/Alpha Size	Display Type	Number of Characters	Millicandela Rating	Common Pin	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Wavelength - Peak	Voltage - Forward (Vf) (Typ)
Lumex Opto/Components Inc. LDQ-M283RI	Yellow	12-DIP	7.62 mm	0.3 in	10 mA	105 mW	7 mm	0.28 in	7-Segment	4	3 mcd	Common Anode	32.2 mm	0.402 in	1.268 in	5.8 mm	0.228 "	10.2 mm	585 nm	2.1 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

LDQ-M283 Series

Display Modules - LED Character and Numeric Yellow 7-Segment 4 Character Common Anode 2.1V 10mA 0.402" H x 1.268" W x 0.228" D (10.20mm x 32.20mm x 5.80mm) 12-DIP (0.300", 7.62mm)
