TRA9023P

Active

TE Connectivity Raychem Cable Protection

ANTENNA PHANTOM 3DBI GAIN 928MHZ

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

ANTENNA PHANTOM 3DBI GAIN 928MHZ

Technical Specifications

Parameters and characteristics for this part

Part	Frequency Range [Max]	Frequency Range [Min]	Number of Bands	Height (Max) [Max] [z]	Height (Max)	Applications	Power - Max [Max]	Gain	Frequency (Center/Band)	Termination	Antenna Type	RF Family/Standard	Frequency Group [Max]	Frequency Group [Min]	Mounting Type	VSWR	Frequency Group	Height (Max) [Max]
TE Connectivity Raychem Cable Protection TRA9023P	928 MHz	902 MHz	1	2.7 in	68.58 mm	GSM	150 W	3 dBi	915 MHz	N Type Female	Dome	Cellular	1 GHz	300 MHz
TE Connectivity Raychem Cable Protection TRA9023N	915 MHz	902 MHz	1	2.7 in	68.58 mm		100 W	3 dBi	915 MHz	NMO	Dome		1 GHz	300 MHz	Base Mount
TE Connectivity Raychem Cable Protection TRA9023NP	928 MHz	902 MHz	1		69.85 mm	Bluetooth GSM WLAN	100 W	3 dBi	915 MHz	NMO	Dome	Bluetooth Cellular WiFi			Connector Mount	2	Wide Band	2.75 in
TE Connectivity Raychem Cable Protection TRA9023P	928 MHz	902 MHz	1	2.7 in	68.58 mm	GSM	150 W	3 dBi	915 MHz	N Type Female	Dome	Cellular	1 GHz	300 MHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Baton/Stick Antenna, Single Band, ISM / LoRaWAN, External Mount, Stud/Screw/Lug Mount, N-type, Omnidirectional, Single Port, 0 < 3 dBi Peak Gain
