GDT28H-130-A

Active

Bourns Inc.

GAS DISCHARGE TUBES 1300VDC 5KADC 1.5PF SOLDER PAD SMD

Search across all available documentation for this part.

Active

Bourns Inc.

GAS DISCHARGE TUBES 1300VDC 5KADC 1.5PF SOLDER PAD SMD

Technical Specifications

Parameters and characteristics for this part

Specification	GDT28H-130-A

Fail Short	False
Impulse Discharge Current (8/20µs)	5000 A
Impulse Discharge Current (8/20µs)	5 kA
Mounting Type	Through Hole
Number of Poles	2
Package / Case	Axial Cylinder
Tolerance	20 %
Voltage - DC Spark Over (Nom)	1300 V

Part	Voltage - DC Spark Over (Nom)	Mounting Type	Tolerance	Impulse Discharge Current (8/20µs)	Impulse Discharge Current (8/20µs)	Package / Case	Number of Poles	Kit Contents	Kit Contents	Kit Type
Bourns Inc. GDT28H-120-A	1200 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. GDT28H-150-A	1500 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. GDT28H-250-B	2500 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. GDT28H-250-BRP	2500 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. GDT28H-250-A	2500 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. GDT28H-330-B	3300 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. GDT28H-130-A	1300 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. GDT28H-120-B	1200 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2
Bourns Inc. DK-GDT28H-01								4 Values (5 Each)	20 Pieces	Gas Discharge Tubes
Bourns Inc. GDT28H-120-BRP	1200 V	Through Hole	20 %	5000 A	5 kA	Axial Cylinder	2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1000	$ 0.94

General part information

Gas Discharge Tube 1300 V 5000A (5kA) ±20% 2 Pole Through Hole
