FN3120H-110-35

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 110A CHASSIS MOUNT

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 110A CHASSIS MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	FN3120H-110-35

Applications	Regenerative Motor Drive
Approval Agency	CSA, ENEC, UR
Configuration	Single Stage
Current	110 A
Filter Type	Three Phase (Delta)
Frequency - Operating [Max]	60 Hz
Frequency - Operating [Min]	DC
Mounting Type	Chassis Mount
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Terminal Block
Voltage - Rated AC (Phase to Ground/Neutral)	300 V
Voltage - Rated AC (Phase to Phase)	520 V

Part	Mounting Type	Operating Temperature [custom]	Frequency - Operating [Max]	Frequency - Operating [Min]	Filter Type	Applications	Voltage - Rated AC (Phase to Phase)	Termination Style	Voltage - Rated AC (Phase to Ground/Neutral)	Approval Agency	Configuration	Current
TE Connectivity Raychem Cable Protection FN3120H-80-35	Chassis Mount	-25 °C 100 °C	60 Hz	DC	Three Phase (Delta)	Regenerative Motor Drive	520 V	Terminal Block	300 V	CSA ENEC UR	Single Stage	80 A
TE Connectivity Raychem Cable Protection FN3120H-110-35	Chassis Mount	-25 °C 100 °C	60 Hz	DC	Three Phase (Delta)	Regenerative Motor Drive	520 V	Terminal Block	300 V	CSA ENEC UR	Single Stage	110 A
TE Connectivity Raychem Cable Protection FN3120H-230-40	Chassis Mount	-25 °C 100 °C	60 Hz	DC	Three Phase (Delta)	Regenerative Motor Drive	520 V	Terminal Block	300 V	CSA ENEC UR	Single Stage	230 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Three Phase (Delta) EMC/EMI Line Filter 110 A DC ~ 60Hz Single Stage Terminal Block
