FN510-66-34

Obsolete

TE Connectivity Raychem Cable Protection

LINE FILTER 66A CHASSIS MOUNT

Search across all available documentation for this part.

Obsolete

TE Connectivity Raychem Cable Protection

LINE FILTER 66A CHASSIS MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	FN510-66-34

Applications	General Purpose
Current	66 A
Filter Type	Three Phase (Delta)
Mounting Type	Chassis Mount
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Termination Style	Terminal Block
Voltage - Rated AC (Phase to Ground/Neutral)	288 V
Voltage - Rated AC (Phase to Phase)	500 V

Part	Mounting Type	Voltage - Rated AC (Phase to Phase)	Current	Applications	Voltage - Rated AC (Phase to Ground/Neutral)	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Filter Type
TE Connectivity Raychem Cable Protection FN510-24-33	Chassis Mount	500 V	24 A	General Purpose	288 V	Terminal Block	70 °C	-25 °C	Three Phase (Delta)
TE Connectivity Raychem Cable Protection FN510-12-29	Chassis Mount	500 V	12 A	General Purpose	288 V	Terminal Block	70 °C	-25 °C	Three Phase (Delta)
TE Connectivity Raychem Cable Protection FN510-16-29	Chassis Mount	500 V	16 A	General Purpose	288 V	Terminal Block	70 °C	-25 °C	Three Phase (Delta)
TE Connectivity Raychem Cable Protection FN510-66-34	Chassis Mount	500 V	66 A	General Purpose	288 V	Terminal Block	70 °C	-25 °C	Three Phase (Delta)
TE Connectivity Raychem Cable Protection FN510-50-34	Chassis Mount	500 V	50 A	General Purpose	288 V	Terminal Block	70 °C	-25 °C	Three Phase (Delta)
TE Connectivity Raychem Cable Protection FN510-4-29	Chassis Mount	500 V	4 A	General Purpose	288 V	Terminal Block	70 °C	-25 °C	Three Phase (Delta)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Three Phase (Delta) EMC/EMI Line Filter 66 A Terminal Block
