Specification	UB216SKG036CF

Actuator Marking	No Marking
Actuator Type	Plunger for Cap
Circuit	SPDT
Color	Green, Red
Current Rating	0.4 VA
Electrical Life (Cycles)	200000
Features	Fully, Sealed
Illumination Type	LED
Illumination Voltage (Nominal)	2.1 VDC, 3.5 VDC
Illumination Voltage (Nominal)	2.1, 3.5 VDC
Mechanical Life (Cycles)	200000 Cycles
Mounting Type	Through Hole
Operating Temperature (Max)	50 °C
Operating Temperature (Min)	-25 °C
Switch Function	On-On
Termination Style	PC Pin
Type	Standard, Illuminated
Voltage Rating - AC	28 V
Voltage Rating - DC	28 V

UB216SK Series

Part	Mechanical Life (Cycles)	Electrical Life (Cycles)	Termination Style	Circuit	Actuator Type	Color	Illumination Type	Actuator Marking	Switch Function	Operating Temperature (Min)	Operating Temperature (Max)	Mounting Type	Type	Features	Current Rating	Voltage Rating - AC	Illumination Voltage (Nominal)	Illumination Voltage (Nominal)	Voltage Rating - DC	Color - Actuator/Cap
NKK Switches UB216SKG03N-5C	200000 Cycles	200000	PC Pin	SPDT	Button Square	Green Red	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	0.4 VA	28 V	2.1 VDC 3.5 VDC	2.1 3.5 VDC	28 V	Clear
NKK Switches UB216SKW035F-1JC	200000 Cycles	10000 Cycles	PC Pin	SPDT	Button Square	Green	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	5 A	125 V	2.1 VDC		30 V	Clear (Red Filter/Diffuser)
NKK Switches UB216SKG036CF	200000 Cycles	200000	PC Pin	SPDT	Plunger for Cap	Green Red	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	0.4 VA	28 V	2.1 VDC 3.5 VDC	2.1 3.5 VDC	28 V
NKK Switches UB216SKW036F	200000 Cycles	10000 Cycles	PC Pin	SPDT	Plunger for Cap	Green	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	5 A	125 V	3.5 VDC		30 V
NKK Switches UB216SKW036F-3JB	200000 Cycles	10000 Cycles	PC Pin	SPDT	Button Square	Green	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	5 A	125 V	3.5 VDC		30 V	Clear (White Filter/Diffuser)
NKK Switches UB216SKW036G-1JB	200000 Cycles	10000 Cycles	PC Pin	SPDT	Button Square	Blue	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	5 A	125 V	2.9 VDC		30 V	Clear (White Filter/Diffuser)
NKK Switches UB216SKW035D-1JD	200000 Cycles	10000 Cycles	PC Pin	SPDT	Button Square	Amber	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	5 A	125 V	2 VDC		30 V	Clear (Amber Filter/Diffuser)
NKK Switches UB216SKG036CF-1JB	200000 Cycles	200000	PC Pin	SPDT	Button Square	Green Red	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	0.4 VA	28 V	2.1 VDC 3.5 VDC	2.1 3.5 VDC	28 V	Clear (White Filter/Diffuser)
NKK Switches UB216SKG035C-1JC	200000 Cycles	200000	PC Pin	SPDT	Button Square	Red	LED	No Marking	On-On	-25 °C	50 °C	Through Hole	Illuminated Standard	Fully Sealed	0.4 VA	28 V	1.85 VDC		28 V	Clear (Red Filter/Diffuser)
NKK Switches UB216SKW03N	200000 Cycles	10000 Cycles	PC Pin	SPDT	Plunger for Cap			No Marking	On-On	-25 °C	70 °C	Through Hole	Standard	Fully Sealed	5 A	125 V			30 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

UB216SKG036CF | Datasheet

UB2 Indicators
