F881KM472M300L

Active

KEMET

CAP FILM 4700PF 20% 1KVDC RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 4700PF 20% 1KVDC RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	F881KM472M300L

Applications	EMI, RFI Suppression
Capacitance	4700 pF
Dielectric Material	Metallized, Polypropylene (PP)
Height - Seated (Max) [Max]	0.354 in
Height - Seated (Max) [Max]	9 mm
Lead Spacing	0.394 in
Lead Spacing	10 mm
Mounting Type	Through Hole
Operating Temperature [Max]	110 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial
Size / Dimension [x]	13 mm
Size / Dimension [x]	0.512 in
Size / Dimension [y]	4 mm
Size / Dimension [y]	0.157 in
Termination	PC Pins
Tolerance	20 %
Voltage Rating - AC	300 V
Voltage Rating - DC	1 kVDC
Voltage Rating - DC	1 kV

Part	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Package / Case	Dielectric Material	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Voltage Rating - DC	Voltage Rating - DC	Capacitance	Applications	Mounting Type	Voltage Rating - AC	Operating Temperature [Min]	Operating Temperature [Max]	Termination
KEMET F881KM472M300L	20 %	0.354 in	9 mm	0.394 in	10 mm	Radial	Metallized Polypropylene (PP)	4 mm	13 mm	0.157 in	0.512 in	1 kVDC	1 kV	4700 pF	EMI RFI Suppression	Through Hole	300 V	-40 °C	110 °C	PC Pins

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4700 pF Film Capacitor 300V 1000V (1kV) Polypropylene (PP), Metallized Radial
