FETA2500B-36
ActiveCosel USA, Inc.
AC/DC CONVERTER 36V 1980W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FETA2500B-36
ActiveCosel USA, Inc.
AC/DC CONVERTER 36V 1980W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FETA2500B-36 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus, DEMKO, CE |
| Current - Output 1 | 55 A |
| Efficiency | 90 % |
| Features | Adjustable Output, PFC |
| Mounting Type | Rack Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -10 °C |
| Size / Dimension [x] | 13.39 in |
| Size / Dimension [x] | 340 mm |
| Size / Dimension [y] | 4.02 in |
| Size / Dimension [y] | 102 mm |
| Size / Dimension [z] | 41 mm |
| Size / Dimension [z] | 1.61 " |
| Type | Front End |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 170 VAC |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 36 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 759.87 | |
| 5 | $ 715.86 | |||
| 10 | $ 697.70 | |||
Description
General part information
FETA2500 Series
Front End AC DC Converters 1 Output 36V 170 ~ 264 VAC Input
