TS-114-G-G-1

Active

Samtec Inc.

CONN HEADER VERT 14POS 2.54MM

Search across all available documentation for this part.

Active

Samtec Inc.

CONN HEADER VERT 14POS 2.54MM

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Termination	Color	Contact Finish Thickness	Contact Finish Thickness	Pitch [x]	Pitch [x]	Number of Rows	Number of Positions	Contact Finish	Connector Type
Samtec Inc. TS-114-T-A-1	Through Hole	Solder	Black	200 Áin	5.08 Ám	2.54 mm	0.1 in	1	14	Tin	Header
Samtec Inc. TS-114-T-AA	Through Hole	Solder	Black	200 Áin	5.08 Ám	2.54 mm	0.1 in	1	14	Tin	Header
Samtec Inc. TS-114-G-A	Through Hole	Solder	Black	20 µin	0.51 µm	2.54 mm	0.1 in	1	14	Gold	Header
Samtec Inc. TS-114-G-G-1	Through Hole	Solder	Black	20 µin	0.51 µm	2.54 mm	0.1 in	1	14	Gold	Header

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	16	$ 5.31

General part information

14 Position Header Connector Post Gold
