Technical Specifications
Parameters and characteristics for this part
| Specification | 48.52.8.024.0060SPA |
|---|---|
| Coil Current | 46 mA |
| Coil Type | Non Latching |
| Coil Voltage | 24 VAC |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 8 A |
| Features | Varistor, Lighted Indicator |
| Load - Max Switching | 3200 VA |
| Mounting Type | DIN Rail |
| Must Operate Voltage | 19.2 VAC |
| Must Release Voltage | 4.8 VAC |
| Operate Time | 7 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 4 ms |
| Switching Voltage [Max] | 400 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 19.93 | |
| 10 | $ 17.71 | |||
| 30 | $ 16.83 | |||
| 50 | $ 15.94 | |||
| 100 | $ 15.06 | |||
| 250 | $ 13.73 | |||
| 500 | $ 12.84 | |||
Description
General part information
48.52.8 Series
General Purpose Relay DPDT (2 Form C) 24VAC Coil DIN Rail
