Specification	1218805

Cable Length	78.74 in
Connection Method	Cable
Ingress Protection	IP69K, IP66, IP67
Light Source	Red LED
Operating Temperature (Max)	60 °C
Operating Temperature (Min)	-40 °C
Output Configuration	Light-ON - Selectable, Dark-ON, PNP, Selectable, Light-ON, PNP - Dark-ON, NPN
Response Time	500 µs
Sensing Distance Maximum	748.031 "
Sensing Distance Minimum	9.843 "
Sensing Method	Retroreflective
Voltage - Supply (Maximum)	30 VDC
Voltage - Supply (Minimum)	10 VDC

WLD26P Series

Part	Operating Temperature (Max)	Operating Temperature (Min)	Connection Method	Sensing Distance Maximum	Sensing Distance Minimum	Ingress Protection	Output Configuration	Cable Length	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Sensing Method	Light Source	Response Time
SICK, Inc. 1218805	60 °C	-40 °C	Cable	748.031 "	9.843 "	IP66 IP67 IP69K	Dark-ON Light-ON Light-ON - Selectable NPN PNP PNP - Dark-ON Selectable	78.74 in	10 VDC	30 VDC	Retroreflective	Red LED	500 µs
