4920-1-5

Active

3M (TC)

TAPE DBL SIDED WHITE 1"X5YDS

Search across all available documentation for this part.

Active

3M (TC)

TAPE DBL SIDED WHITE 1"X5YDS

Technical Specifications

Parameters and characteristics for this part

Specification	4920-1-5

Adhesive	Acrylic
Backing, Carrier	Paper
Color	White
Length	4.6 m
Length	15 ft
Length	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Storage/Refrigeration Temperature [Max]	100 °F, 38 °C
Storage/Refrigeration Temperature [Min]	40 °F, 4 °C
Tape Type	Double Coated, Double Sided
Temperature Range	93 °C
Temperature Range	200 °F
Thickness	0.381 mm
Thickness	0.015 in
Thickness	0.381 mm
Thickness - Adhesive	12 mils
Thickness - Adhesive	0.012 "
Thickness - Adhesive	0.305 mm
Thickness - Backing, Carrier	0.003 in
Thickness - Backing, Carrier	3 mils
Thickness - Backing, Carrier	0.076 mm
Width [x]	25.4 mm
Width [x]	1 in

Part	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Shelf Life Start	Length	Length	Length	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Tape Type	Width [x]	Width [x]	Temperature Range	Temperature Range	Thickness	Thickness	Thickness	Color	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Backing, Carrier	Shelf Life	Adhesive	Width	Width	Width
3M (TC) 4920-1-5	0.003 in	3 mils	0.076 mm	Date of Shipment	4.6 m	15 ft	5 yd	12 mils	0.012 "	0.305 mm	Double Coated Double Sided	25.4 mm	1 in	93 °C	200 °F	0.381 mm	0.015 in	0.381 mm	White	4 °C 40 °F	38 °C 100 °F	Paper	24 Months	Acrylic
3M (TC) 4920-0.5-5	0.003 in	3 mils	0.076 mm	Date of Shipment	4.6 m	15 ft	5 yd	12 mils	0.012 "	0.305 mm	Double Coated Double Sided			93 °C	200 °F	0.381 mm	0.015 in	0.381 mm	White	4 °C 40 °F	38 °C 100 °F	Paper	24 Months	Acrylic	0.5 in	12.7 mm	0.5 in
3M (TC) 4920-0.75-5	0.003 in	3 mils	0.076 mm	Date of Shipment	4.6 m	15 ft	5 yd	12 mils	0.012 "	0.305 mm	Double Coated Double Sided			93 °C	200 °F	0.381 mm	0.015 in	0.381 mm	White	4 °C 40 °F	38 °C 100 °F	Paper	24 Months	Acrylic	19.05 mm	0.75 in	0.75 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Double Coated, Double Sided Tape Acrylic Adhesive White 1.00" (25.40mm) X 15' (4.6m) 5 yds
