C4126A.30.10

Active

Prysmian Group

CABLE 3COND 18AWG GRAY

Search across all available documentation for this part.

Active

Prysmian Group

CABLE 3COND 18AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	C4126A.30.10

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	16
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	5.99 mm
Jacket (Insulation) Diameter [diameter]	0.236 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Gray
Length	1000 ft
Length	304.8 m
Number of Conductors	3
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-20 C
Usage	Control, Communication
Voltage	300 V
Wire Gauge	18 AWG

Part	Wire Gauge	Conductor Insulation	Length	Length	Jacket Color	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage	Number of Conductors	Usage	Conductor Material
Prysmian Group C4126A.30.10	18 AWG	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	Gray	16	30 AWG	Poly-Vinyl Chloride (PVC)	Multi-Conductor	5.99 mm	0.236 in	-20 C	105 ░C	300 V	3	Communication Control	Copper Tinned

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	25000	$ 0.60

General part information

3 Conductor Multi-Conductor Cable Gray 18 AWG 1000.0' (304.8m)

Technical documentation and resources

No documents available
