SE2576L-EK1

Active

Skyworks Solutions Inc.

EVAL KIT FOR SE2576L

Search across all available documentation for this part.

Active

Skyworks Solutions Inc.

EVAL KIT FOR SE2576L

Technical Specifications

Parameters and characteristics for this part

Specification	SE2576L-EK1

For Use With/Related Products	SE2576L
Frequency	2.4 GHz
Supplied Contents	Board(s)
Type	Power Amplifier

Part	Supplier Device Package	Frequency [Max]	Frequency [Min]	Package / Case	Voltage - Supply [Min]	Voltage - Supply [Max]	Gain	Current - Supply	Test Frequency [Max]	Test Frequency [Min]	P1dB	RF Type	Mounting Type	Type	Supplied Contents	For Use With/Related Products	Frequency
Skyworks Solutions Inc. SE2576L-R	16-QFN (3x3)	2.5 GHz	2.4 GHz	16-VFQFN Exposed Pad	4.5 V	5.5 V	33 dB	650 mA	2.5 GHz	2.4 GHz	32 dBm	802.11b/g/n	Surface Mount
Skyworks Solutions Inc. SE2576L-EK1														Power Amplifier	Board(s)	SE2576L	2.4 GHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 105.19

General part information

- SE2576L Power Amplifier 2.4GHz Evaluation Board
