DC0011/06-TG-AH482-2.0-0

Obsolete

t-Global Technology

THERM PAD 18.03MMX12.7MM RED

Search across all available documentation for this part.

Obsolete

t-Global Technology

THERM PAD 18.03MMX12.7MM RED

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Thermal Pad Red 18.03mm x 12.70mm Rectangular

Technical documentation and resources

Part	Type	Material	Thickness [x]	Thickness [x]	Shape	Usage	Thermal Conductivity	Shelf Life	Color	Outline [x]	Outline [y]	Backing, Carrier	Thickness	Thickness	Shelf Life Start	Adhesive	Thickness [custom]	Thickness [custom]
t-Global Technology DC0011/06-TI900-0.12-0	Die-Cut Pad, Sheet	Silicone	0.005 in	0.127 mm	Rectangular	TO-220	1.8 W/m-K	24 Months	White	18.03 mm	12.7 mm	Viscose
t-Global Technology DC0011/06-TG-AH482-2.0-0	Die-Cut Pad, Sheet				Rectangular	TO-220	2.2 W/m-K	24 Months	Red	18.03 mm	12.7 mm		0.008 in	0.203 mm
t-Global Technology DC0011/06-TG-A482K-0.1-0	Die-Cut Pad, Sheet	Silicone			Rectangular	TO-220	2.3 W/m-K	24 Months	Red	18.03 mm	12.7 mm		0.0039 in	0.1 mm	Date of Purchase
t-Global Technology DC0011/06-TI900-0.12-2A	Die-Cut Pad, Sheet	Silicone	0.005 in	0.127 mm	Rectangular	TO-220	1.8 W/m-K	24 Months	White	18.03 mm	12.7 mm	Viscose				Adhesive - Both Sides
t-Global Technology DC0011/06-TG-A486G-0.3-2A	Die-Cut Pad, Sheet				Rectangular	TO-220	6 W/m-K	12 Months	Gray	18.03 mm	12.7 mm				Date of Purchase	Adhesive - Both Sides	0.305 mm	0.012 "
t-Global Technology DC0011/06-TG-A373F-0.25-2A	Die-Cut Pad, Sheet				Rectangular	TO-220	1.4 W/m-K	12 Months	Yellow	18.03 mm	12.7 mm					Adhesive - Both Sides	0.254 mm	0.01 in
