EML15US48-P

Active

XP POWER

AC/DC CONVERTER 48V 15W

Search across all available documentation for this part.

Active

XP POWER

AC/DC CONVERTER 48V 15W

Technical Specifications

Parameters and characteristics for this part

Part	Type	Standard Number	Applications	Approval Agency	Power (Watts)	Features	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Outputs	Load Regulation	Weight	Weight	Voltage - Output 1	Line Regulation	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Package / Case	Current - Output (Max) [Max]	Size / Dimension [y]	Size / Dimension [z]
XP POWER EML15US48-E	Enclosed	60601-1	Medical	CE cULus TUV	15 W	Universal Input	Through Hole	-20 °C	70 °C	1	1 %	90.72 g	0.2 lb	48 V	0.5 %	65 mm	33.3 mm	1.31 "	2.56 in	0.96 "	24.4 mm	4-DIP Module	320 mA
XP POWER EML15US48-P	Open Frame	60601-1	Medical	CE cULus TUV	15 W	Universal Input	Through Hole	-20 °C	70 °C	1	1 %	31.75 g	0.07 lb	48 V	0.5 %	62 mm		1.21 in	2.44 in	0.96 "		4-DIP Module	320 mA	30.7 mm	24.4 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 34.16

General part information

Open Frame AC DC Converters 1 Output 48V 320mA 85 ~ 264 VAC Input
