JPLUS6T72SE
ActiveBelden Inc.
CBL ASSY 7/16 DIN PLUG-PLUG 6'
JPLUS6T72SE
ActiveBelden Inc.
CBL ASSY 7/16 DIN PLUG-PLUG 6'
Description
General part information
JPLUS6 Series
Cable Assembly Coaxial 7/16 DIN to 7/16 DIN RG-6 72.0" (1.8m) 6.0'
Technical Specifications
Parameters and characteristics for this part
| Specification | JPLUS6T72SE |
|---|---|
| 1st Connector | 7/16 Plug |
| 1st Connector - Type | Plug |
| 1st Connector Dimension (1) | 7 mm |
| 1st Connector Dimension (2) | 16 mm |
| 1st Contact Gender | Male |
| 2nd Connector | 7/16 Plug |
| 2nd Contact Gender | Male |
| Cable Impedance | 75 Ohms |
| Cable Type | 6, RG |
| Color | Black |
| Length | 72 in |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -40 °C |
| Overall Impedance | 75 Ohms |
| Style | 7/16 DIN to 7/16 DIN |
