D38999/26SB98SN

Active

Amphenol Aerospace Operations

CONN PLUG FMALE 6POS GOLD CRIMP

Search across all available documentation for this part.

Active

Amphenol Aerospace Operations

CONN PLUG FMALE 6POS GOLD CRIMP

Technical Specifications

Parameters and characteristics for this part

Specification	D38999/26SB98SN

Applications	Aviation, Aerospace, Marine, Military
Color	Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	1.27 µm
Contact Finish Thickness - Mating	50 µin
Contact Material	Copper Alloy
Features	Coupling Nut, Firewall Usage
Grade	Military
Mounting Type	Free Hanging (In-Line)
Number of Positions	6
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-65 ░C
Orientation	N
Primary Material	Metal
Qualification	MIL-DTL-38999 Series III
Shell Finish	Nickel
Shell Material	Stainless Steel
Shell Size - Insert	11-98
Shell Size, MIL	B
Shielding	Shielded
Termination	Crimp

Part	Note	Number of Positions	Housing Color	Grade	Contact Size	Contact Type	Qualification	Type	Shell Finish	Features	Connector Type	Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Shielding	Contact Shape	Mounting Type	Shell Material	Shell Size, MIL	Shell Size - Insert	Termination	Primary Material	Contact Finish - Mating	Applications	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Color	Contact Material
Amphenol Aerospace Operations D38999/26SB98PNLC	Contacts Not Included	6	Silver	Military	20	Crimp	MIL-DTL-38999 Series III	For Male Pins	Nickel	Coupling Nut Firewall Usage Self Locking	Plug Housing	N	-65 ░C	200 °C	Shielded	Circular	Free Hanging (In-Line)	Stainless Steel	B	11-98
Amphenol Aerospace Operations D38999/26SB98SN		6		Military			MIL-DTL-38999 Series III		Nickel	Coupling Nut Firewall Usage	Female Sockets Plug	N	-65 ░C	200 °C	Shielded		Free Hanging (In-Line)	Stainless Steel	B	11-98	Crimp	Metal	Gold	Aerospace Aviation Marine Military	1.27 µm	50 µin	Silver	Copper Alloy

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

6 Position Circular Connector Plug, Female Sockets Crimp
