PS2P-CON-CE-M001-2AA-C0002-ERA360-05

Active

Amphenol Piher Sensing Systems

ROTARY TOUCHLESS MAGNETIC POSITI

Search across all available documentation for this part.

Active

Amphenol Piher Sensing Systems

ROTARY TOUCHLESS MAGNETIC POSITI

Technical Specifications

Parameters and characteristics for this part

Specification	PS2P-CON-CE-M001-2AA-C0002-ERA360-05

Actuator Type	External Magnet, Included
For Measuring	Linear, Rotary, Angle
Linearity	1 %
Mounting Type	Chassis Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Output	Analog Voltage
Package / Case	Box with Wire Leads
Rotation Angle - Electrical, Mechanical [Max]	360 °
Rotation Angle - Electrical, Mechanical [Min]	0 °
Technology	Hall Effect
Termination Style	Wire Leads
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	4.5 V

ROTARY TOUCHLESS MAGNETIC POSITI

Part	Actuator Type	Rotation Angle - Electrical, Mechanical [Max]	Rotation Angle - Electrical, Mechanical [Min]	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Technology	Output	Package / Case	Linearity	Voltage - Supply [Min]	Voltage - Supply [Max]	Mounting Type	For Measuring
Amphenol Piher Sensing Systems PS2P-CON-CE-M001-2AA-C0002-ERA360-05	External Magnet, Included	360 °	0 °	Wire Leads	125 °C	-40 °C	Hall Effect	Analog Voltage	Box with Wire Leads	1 %	4.5 V	5.5 V	Chassis Mount	Angle, Linear, Rotary

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Hall Effect Sensor Angle, Linear, Rotary External Magnet, Included Wire Leads
