0203004.HXG

Active

LITTELFUSE

FUSE 250V SB FLAT-PAK W/GULL-WING 4A/ TUBE

Search across all available documentation for this part.

Active

LITTELFUSE

FUSE 250V SB FLAT-PAK W/GULL-WING 4A/ TUBE

Technical Specifications

Parameters and characteristics for this part

Specification	0203004.HXG

Approval Agency	CSA, UL
Breaking Capacity @ Rated Voltage	50 A
Current Rating (Amps)	4 A
DC Cold Resistance	0.0148 Ohms
Fuse Type	Board Mount
Melting I²t	8.75
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	2-SMD, Gull Wing
Response Time	Slow Blow
Size / Dimension [x]	9.45 mm
Size / Dimension [x]	0.372 in
Size / Dimension [y]	6.35 mm
Size / Dimension [y]	0.25 in
Size / Dimension [z]	4.19 mm
Size / Dimension [z]	0.165 in
Voltage Rating - AC	250 V

FUSE 250V SB FLAT-PAK W/GULL-WING 4A

Part	Current Rating (Amps)	Voltage Rating - AC	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Approval Agency	Melting I²t	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Breaking Capacity @ Rated Voltage	Response Time	Fuse Type	DC Cold Resistance
LITTELFUSE 0203004.HXG	4 A	250 V	4.19 mm	9.45 mm	0.372 in	0.165 in	6.35 mm	0.25 in	CSA, UL	8.75	2-SMD, Gull Wing	-55 °C	125 °C	Surface Mount	50 A	Slow Blow	Board Mount	0.0148 Ohms

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

FUSE 250V SB FLAT-PAK W/GULL-WING 4A
