SMA512LB G/W

Active

American Opto Plus LED

DISP 14SEG 0.51 DUAL BLUE 10DIP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

SMA512LB G/W

Active

American Opto Plus LED

DISP 14SEG 0.51 DUAL BLUE 10DIP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	SMA512LB G/W	SMA512 Series

Color	Blue	Blue, Yellow-Green
Common Pin	Common Anode	Common Anode
Current - Test	20 mA	20 mA
Digit/Alpha Size	0.51 in	0.51 in
Digit/Alpha Size	13 mm	13 mm
Display Type	7-Segment	7-Segment
Millicandela Rating	40 mcd	12 - 40 mcd
Number of Characters	2	2
Package / Case	10-DIP	10-DIP
Power Dissipation (Max) [Max]	120 mW	70 - 120 mW
Size / Dimension [x]	18 mm	18 mm
Size / Dimension [x]	0.709 in	0.709 in
Size / Dimension [y]	0.964 in	0.964 in
Size / Dimension [y]	24.5 mm	24.5 mm
Size / Dimension [z]	0.147 in	0.147 in
Size / Dimension [z]	3.75 mm	3.75 mm
Voltage - Forward (Vf) (Typ)	3.2 V	2.1 - 3.2 V
Wavelength - Peak	-	573 nm

SMA512 Series

DISP 14SEG 0.51 DUAL BLUE 10DIP

Part	Voltage - Forward (Vf) (Typ)	Millicandela Rating	Current - Test	Package / Case	Number of Characters	Display Type	Power Dissipation (Max) [Max]	Common Pin	Color	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Digit/Alpha Size	Digit/Alpha Size	Wavelength - Peak
American Opto Plus LED SMA512LB G/W	3.2 V	40 mcd	20 mA	10-DIP	2	7-Segment	120 mW	Common Anode	Blue	18 mm	0.964 in	0.147 in	0.709 in	3.75 mm	24.5 mm	0.51 in	13 mm
American Opto Plus LED SMA512YG G/W	2.1 V	12 mcd	20 mA	10-DIP	2	7-Segment	70 mW	Common Anode	Yellow-Green	18 mm	0.964 in	0.147 in	0.709 in	3.75 mm	24.5 mm	0.51 in	13 mm	573 nm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1	$ 5.28
		10	$ 3.96
		100	$ 3.30
		500	$ 2.31
		750	$ 2.11

Description

General part information

SMA512 Series

Display Modules - LED Character and Numeric Blue 7-Segment 2 Character Common Anode 3.2V 20mA 0.709" H x 0.964" W x 0.147" D (18.00mm x 24.50mm x 3.75mm) 10-DIP
