EPM30-180-BE-0F0

Active

Astrodyne TDI

AC/DC CONVERTER 18V 30W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

EPM30-180-BE-0F0

Active

Astrodyne TDI

AC/DC CONVERTER 18V 30W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	EPM30-180-BE-0F0

Applications	Medical
Approval Agency	cTUVus, TUV, CB, CE
Current - Output (Max) [Max]	1.67 A
Efficiency	87.5 %
Features	Universal Input
Line Regulation	0.5 %
Load Regulation	3 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	4 Lead
Package / Case	5-DIP Module
Power (Watts)	30 W
Type	Enclosed
Voltage - Input [Max]	275 VAC
Voltage - Input [Min]	80 VAC
Voltage - Output 1	18 V

EPM30 Series

Part	Operating Temperature [Max]	Operating Temperature [Min]	Features	Number of Outputs	Efficiency	Load Regulation	Voltage - Input [Min]	Voltage - Input [Max]	Applications	Mounting Type	Line Regulation	Current - Output (Max) [Max]	Voltage - Output 1	Type	Approval Agency	Package / Case	Package / Case	Power (Watts)	Standard Number	Current - Output 1	Voltage - Isolation	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]
Astrodyne TDI EPM30-033-BE-0F0	85 °C	-40 °C	Universal Input	1	87.5 %	3 %	80 VAC	275 VAC	Medical	Through Hole	0.5 %	6.06 A	3.3 V	Enclosed	CB CE cTUVus TUV	4 Lead	5-DIP Module	20 W
Astrodyne TDI EPM30-050-BC-0F0	85 °C	-40 °C	Universal Input	1	87.5 %		80 VAC	275 VAC	Medical	Chassis Mount			5 V	Enclosed	CB CE cTUVus TUV			30 W	60601-1	6 A	4000 V	54.9 mm	95.8 mm	25.4 mm	3.77 "	2.16 "	1 "
Astrodyne TDI EPM30-090-BC-0F0	85 °C	-40 °C	Universal Input	1	87.5 %		80 VAC	275 VAC	Medical	Chassis Mount			9 V	Enclosed	CB CE cTUVus TUV			30 W	60601-1	3.33 A	4000 V	54.9 mm	95.8 mm	25.4 mm	3.77 "	2.16 "	1 "
Astrodyne TDI EPM30-180-BC-0F0	85 °C	-40 °C	Universal Input	1	87.5 %		80 VAC	275 VAC	Medical	Chassis Mount			18 V	Enclosed	CB CE cTUVus TUV			30 W	60601-1	1.67 A	4000 V	54.9 mm	95.8 mm	25.4 mm	3.77 "	2.16 "	1 "
Astrodyne TDI EPM30-090-BE-0F0	85 °C	-40 °C	Universal Input	1	87.5 %	3 %	80 VAC	275 VAC	Medical	Through Hole	0.5 %	3.33 A	9 V	Enclosed	CB CE cTUVus TUV	4 Lead	5-DIP Module	30 W
Astrodyne TDI EPM30-180-BE-0F0	85 °C	-40 °C	Universal Input	1	87.5 %	3 %	80 VAC	275 VAC	Medical	Through Hole	0.5 %	1.67 A	18 V	Enclosed	CB CE cTUVus TUV	4 Lead	5-DIP Module	30 W
Astrodyne TDI EPM30-120-BP-0F0	85 °C	-40 °C	Universal Input	1	87.5 %	3 %	80 VAC	275 VAC	Medical	Through Hole	0.5 %	2.5 A	12 V	Open Frame	CB CE cTUVus TUV	4 Lead	5-DIP Module	30 W					60.5 mm		2.38 "	1.6 "	0.93 in	40.6 mm	23.7 mm
Astrodyne TDI EPM30-180-BP-0F0	85 °C	-40 °C	Universal Input	1	87.5 %	3 %	80 VAC	275 VAC	Medical	Through Hole	0.5 %	1.67 A	18 V	Open Frame	CB CE cTUVus TUV	4 Lead	5-DIP Module	30 W					60.5 mm		2.38 "	1.6 "	0.93 in	40.6 mm	23.7 mm
Astrodyne TDI EPM30-033-BP-0F0	85 °C	-40 °C	Universal Input	1	87.5 %	3 %	80 VAC	275 VAC	Medical	Through Hole	0.5 %	6.06 A	3.3 V	Open Frame	CB CE cTUVus TUV	4 Lead	5-DIP Module	20 W					60.5 mm		2.38 "	1.6 "	0.93 in	40.6 mm	23.7 mm
Astrodyne TDI EPM30-150-BP-0F0	85 °C	-40 °C	Universal Input	1	87.5 %	3 %	80 VAC	275 VAC	Medical	Through Hole	0.5 %	2 A	15 V	Open Frame	CB CE cTUVus TUV	4 Lead	5-DIP Module	30 W					60.5 mm		2.38 "	1.6 "	0.93 in	40.6 mm	23.7 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

EPM30 Series

Enclosed AC DC Converters 1 Output 18V 1.67A 80 ~ 275 VAC Input
