MAXM86146EVSYS#
ActiveAnalog Devices Inc./Maxim Integrated
EVKIT FOR EMBEDDED PPG
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXM86146EVSYS#
ActiveAnalog Devices Inc./Maxim Integrated
EVKIT FOR EMBEDDED PPG
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXM86146EVSYS# | MAXM86146 Series |
|---|---|---|
| Contents | Board(s) | Board(s) |
| Function | Sensor Signal Conditioner | Sensor Signal Conditioner |
| Input Type | - | Digital |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 70 °C |
| Operating Temperature | - | 0 °C |
| Output Type | - | I2C, SPI |
| Package / Case | - | 38-VFLGA Module |
| Primary Attributes | 2-Channel (Dual) | 2-Channel (Dual) |
| Supplied Contents | Board(s) | Board(s) |
| Type | Interface | Interface, Biometric Sensor Hub |
| Utilized IC / Part | MAXM86146 | MAXM86146 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 142.42 | |
MAXM86146 Series
EVKIT FOR EMBEDDED PPG
| Part | Type | Primary Attributes | Utilized IC / Part | Supplied Contents | Function | Contents | Package / Case | Input Type | Operating Temperature [Max] | Operating Temperature [Min] | Output Type | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXM86146EVSYS# | Interface | 2-Channel (Dual) | MAXM86146 | Board(s) | Sensor Signal Conditioner | Board(s) | ||||||
Analog Devices Inc./Maxim Integrated MAXM86146CFU+ | Biometric Sensor Hub | 38-VFLGA Module | Digital | 70 °C | 0 °C | I2C, SPI | Surface Mount |
Description
General part information
MAXM86146 Series
MAXM86146 Sensor Signal Conditioner Interface Evaluation Board
