PWF-02PFFS-SC7001

Active

Amphenol LTW

POWER, PWF, PLASTIC, 12A, 02 PINS, FEMALE CONNECTOR, FEMALE CONTACT, CIRCULAR, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS COMPL

Search across all available documentation for this part.

Active

Amphenol LTW

POWER, PWF, PLASTIC, 12A, 02 PINS, FEMALE CONNECTOR, FEMALE CONTACT, CIRCULAR, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS COMPL

Technical Specifications

Parameters and characteristics for this part

Specification	PWF-02PFFS-SC7001

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	12 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Flange
Number of Positions	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shielding	Unshielded
Voltage Rating	277 V

Part	Ingress Protection	Insert Material	Shielding	Connector Type	Color	Current Rating (Amps)	Number of Positions	Shell Material	Orientation	Contact Material	Primary Material	Operating Temperature [Min]	Operating Temperature [Max]	Voltage Rating	Contact Finish - Mating	Mounting Feature
Amphenol LTW PWF-02PFFS-SC7001	IP67 - Dust Tight Waterproof	Polyamide (PA) Nylon Glass Filled	Unshielded	Receptacle Female Sockets	Black	12 A	2	Glass Filled Nylon Polyamide (PA)	Keyed	Copper Alloy	Plastic	-40 °C	105 ░C	277 V	Gold	Flange

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Position Circular Connector Receptacle, Female Sockets Solder Cup
