IRM-20-5
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 5V 20W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
IRM-20-5
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 5V 20W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | IRM-20-5 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, CE, cURus, TUV |
| Current - Output (Max) [Max] | 4 A |
| Efficiency | 79 % |
| Features | Universal Input |
| Line Regulation | 0.5 % |
| Load Regulation | 1 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -30 °C |
| Package / Case | 4-DIP Module |
| Power (Watts) | 20 W |
| Size / Dimension [x] | 52.4 mm |
| Size / Dimension [x] | 2.06 in |
| Size / Dimension [y] | 27.2 mm |
| Size / Dimension [y] | 1.07 in |
| Size / Dimension [z] | 24 mm |
| Size / Dimension [z] | 0.94 in |
| Type | Enclosed |
| Voltage - Input [Max] | 370 VDC, 264 VAC |
| Voltage - Input [Min] | 85 VAC, 120 VDC |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 10.53 | |
| 5 | $ 9.92 | |||
| 10 | $ 9.66 | |||
| 25 | $ 9.34 | |||
Description
General part information
IRM-20 Series
Enclosed AC DC Converters 1 Output 5V 4A 85 ~ 264 VAC, 120 ~ 370 VDC Input
