415-2"X36YD

Active

3M (TC)

TAPE SPLICING CLEAR 2"X36YDS

Search across all available documentation for this part.

Active

3M (TC)

TAPE SPLICING CLEAR 2"X36YDS

Technical Specifications

Parameters and characteristics for this part

Specification	415-2"X36YD

Adhesive	Acrylic, 400
Backing, Carrier	Polycoated Kraft Liner
Color	Clear
Length	36 yd
Length	32.9 m
Length	108 ft
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Splicing
Temperature Range [Max]	38 °C
Temperature Range [Max]	100 °F
Temperature Range [Min]	21 °C
Temperature Range [Min]	70 °F
Thickness	8 mils
Thickness	0.008 in
Thickness	0.203 mm
Thickness - Adhesive	4 mils
Thickness - Adhesive	0.004 in
Thickness - Adhesive	0.102 mm
Thickness - Backing, Carrier	0.102 mm
Thickness - Backing, Carrier	4 mils
Thickness - Backing, Carrier	0.004 in
Usage	Splicing
Width [y]	2 "
Width [y]	50.8 mm

Part	Temperature Range [Max]	Temperature Range [Min]	Temperature Range [Max]	Temperature Range [Min]	Thickness	Thickness	Thickness	Usage	Width [y]	Width [y]	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Length	Length	Length	Color	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Tape Type	Adhesive	Shelf Life	Backing, Carrier	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Shelf Life Start	Width	Width	Width
3M (TC) 415-2"X36YD	38 °C	21 °C	100 °F	70 °F	8 mils	0.008 in	0.203 mm	Splicing	2 "	50.8 mm	0.102 mm	4 mils	0.004 in	36 yd	32.9 m	108 ft	Clear	70 °F	21 °C	Splicing	Acrylic 400	24 Months	Polycoated Kraft Liner	4 mils	0.004 in	0.102 mm	Date of Manufacture
3M (TC) 415-3/4"X36YD	38 °C	21 °C	100 °F	70 °F	8 mils	0.008 in	0.203 mm	Splicing			0.102 mm	4 mils	0.004 in	36 yd	32.9 m	108 ft	Clear	70 °F	21 °C	Splicing	Acrylic 400	24 Months	Polycoated Kraft Liner	4 mils	0.004 in	0.102 mm	Date of Manufacture	0.75 in	19.05 mm	0.75 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	24	$ 74.08

General part information

Splicing Tape Acrylic, 400 Adhesive Clear 2.00" (50.80mm) X 108' (32.9m) 36 yds
