B72220U2271K501

Active

EPCOS - TDK Electronics

VARISTOR 430V 10KA DISC 20MM

Search across all available documentation for this part.

Active

EPCOS - TDK Electronics

VARISTOR 430V 10KA DISC 20MM

Technical Specifications

Parameters and characteristics commom to parts in this series

VARISTOR 430V 10KA DISC 20MM

Part	Number of Circuits	Varistor Voltage (Max) [Max]	Mounting Type	Capacitance @ Frequency	Varistor Voltage (Min) [Min]	Varistor Voltage (Typ)	Maximum DC Volts [Max]	Energy	Maximum AC Volts [Max]	Package / Case	Current - Surge	Operating Temperature [Min]	Operating Temperature [Max]
EPCOS - TDK Electronics B72220U2271K501	1	473 V	Through Hole	850 pF	387 V	430 V	350 V	215 J	275 V	Disc 20mm	10 kA	-40 °C	125 °C
EPCOS - TDK Electronics B72220U2151K501	1	264 V	Through Hole	1550 pF	216 V	240 V	200 V	120 J	150 V	Disc 20mm	10 kA	-40 °C	125 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	3000	$ 0.43

General part information

430 V 10 kA Varistor 1 Circuit Through Hole Disc 20mm

Technical documentation and resources
